SAGEMCOM F@ST 2704R Reference Manual page 110

6- Advanced parameters
Field
Filter Name
IP Version
Protocol
Source IP
address[/prefix
length]
Source Port
(port or port:port)
Destination IP
address[/prefix
length]
Destination Port
(port or port:port)
WAN interfaces
Field
Select All
pppoe_0_8_32/ppp1
br0/br0
6.4.6.2 MAC Filtering
Object: This menu is used to create IP filters to refuse data from the LAN to the WAN and list the existing
outgoing IP filters.
• In the Advanced Setup menu, select Security > IP MAC Filtering
Page 6-60
Enter a representative name for the filter.
Select the dedicated IP version from the scroll down list (for
example: IPv4).
Select the dedicated protocol from the scroll down list (TCP/UDP,
TCP, UDP, ICMP).
Enter the Source IP address (WAN).
Enter a "Source" port (WAN) or range of ports.
Note: For one port, for example, enter 80.
For a range of ports, enter 80:90.
Enter the destination IP address (LAN).
Enter a "destination" port (LAN) or range of ports.
Note: For one port, for example, enter 80.
For a range of ports, enter 80:90.
Check the box to select all WAN interfaces.
Note: By unchecking the box, no interface is selected
and the other WLAN/LAN interfaces displayed
boxes become unchecked.
Check the box to select the displayed interface.
Check the box to select the displayed interface.
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Action
Action
F@ST 2704R Reference Manual - 253526032-A
Default
value
Checked
Checked
Checked
