Note! Picture quality is relative to distance. The further away a remote computer
is from the Smart 16 IP, the lower the image quality, and the more tuning needed.
So place the higher resolution computers closer to the Switch.
55. Moving the label – F6
Position the Confirmation label anywhere on the screen.
To position the label from the Main window:
1. Navigate to the desired computer using the Up and Down arrow keys.
2. Press F6. The selected screen image and Identification label will appear.
3. Use the arrow keys to move the label to the desired position.
4. Press Esc to save and exit.
56.

Using the Control software

As an alternative to the OSD, you can operate the system with the Control
software located on our website
Smart CAT5 Switch Upgrades page. With the OSD you operate the system and
view the computer screens on the same monitor. The Control software requires 2
monitors: 1 for the software and 1 to view the computer screens.
With the Control software you can:
·
View computers
·
Edit OSD settings
·
Save configurations for future use
·
Read configurations from and write configurations to the Smart 16 IP
Switch
Control software system requirements
·
Pentium 166 or higher computer
·
16Mb RAM
·
Windows 98 and later
·
Free Serial port
Connecting the RS232 Serial cable
To run the software, connect the RS232 Serial cable to the computer containing
the software, and to the Smart Switch. See the Installation Guide.
OPERATING GUIDE
www.minicom.com
70
.
in the Support section on the
