Minicom Smart CAT5 Switch 16 IP Operating Manual page 52

Exclusive access - If a user has the appropriate permission, he can force the
Remote Consoles of all other users to close. No one can open the Remote Console
until this user disables the Exclusive access or logs off.
Readability Filter - Turn the filter on in scaling mode to preserve most of the
screen details. Only available with a Java Virtual Machine version number of 1.3
or higher
Scaling - Scale down the Remote Console. Not all display details will be
preserved.
Mouse handling - The submenu for mouse handling offers 3 options for
synchronizing the host and the client mouse pointer - explained on pages 54 and
54. The option for 'Fast Sync' shows the hotkey if you defined one using the
Remote Console Settings.
Local cursor - Choose a cursor shape for the host mouse. The number of
available shapes depends on the Java Virtual Machine, only version 1.2 or higher
offers the full list.
Chat Window - Opens the Chat window.
Video Settings – To adjust the video settings.
Refresh video - Refreshes the video.
Soft Keyboard - Opens the soft-keyboard menu:
·
Click Show. The soft-keyboard appears.
·
Click Mapping. Choose the desired language and country
Local Keyboard - Used to change the language mapping of your browser
machine running the Remote Console Applet. Normally the Applet determines the
correct value automatically. However, depending on your particular JVM and
your browser machine settings this is not always possible. A typical example is a
German localized system that uses a US-English keyboard mapping. In this case
you have to change the Local Keyboard setting manually to the right language.
KVM keys – Each key represents a port. See page 21 to define hotkeys to switch
to each port. The keys also appear in the toolbar.
Hotkeys - Button Keys simulate keystrokes on the remote system that cannot be
generated locally. To define hotkeys see page 13.
Encoding – Choose the desired options from the Compression and Color Depth
drop down menus.
SMART CAT5 SWITCH 16 IP
51
.
