Telnet server commands
Click help to list the following commands:
cls - Clears screen
quit - Logs out current user and disconnects from the client.
version - Shows all available version numbers
terminal - Starts the terminal passthrough mode for serial port 1. The key
sequence `<esc> exit' switches back to command modus.
12.

Status via IPMI

The Status via IPMI function shows the current values and the min/max-
thresholds of all fans, temperatures and voltages existing in the host system.
Change the thresholds by editing the values and pressing Apply.
The first time you call this page, it can take up to two minutes until the sensor
data appears.
Note: If IPMI is disabled, Status via IPMI and System Log via IPMI are not
available (the menu options are not visible).
13.

Event Log via IPMI

The Event Log via IPMI accesses the SEL (System Event Log) repository and
reads every entry sequentially. The first time you use this function after starting
Smart 16 IP the complete repository has to be read, what may take 1 or 2 minutes.
After reading all entries, Smart 16 IP displays them with their time, sensor and
description in accordance with the filter settings. You have the choice between
several pre-settings (i.e. last day, last week) or an exact declaration of the start
and the end date.
Once you change the filter settings, click `Update' to update the shown entries. If
the Get sensor names box is checked, all sensor IDs are shown with their
respective names.
The time shown in the log entries is the SEL time, meaning it is independent of
the system time. The SEL time is shown at the top of the log table. Click Clear
Event Log to delete all entries in the SEL repository.
14. File transfer – Virtual Floppy
This feature is not implemented in Smart 16 IP.
