OPERATING GUIDE
Serial line speed - Most modems today will support the default value of 115200
bps. For older modems lower the speed.
Modem Init String - Initialization string. The default value works with all
modern standard modems connected to a telephone line. For special modems or if
connected to a local telephone switch that requires a special dial sequence to
connect to the public telephone network, change this setting by giving a new
string. See the modem's manual about the AT command syntax.
Modem Server IP address – This address is used only when connecting to Smart
16 IP via a modem. When you dial into the Smart 16 IP the client computer will
receive a Modem Client IP address from the Smart 16 IP. Open the Web browser
and type Modem server IP address to login to the Smart 16 IP.
The Client IP (see paragraph below) must be in the same class C subnet as the
server IP. This subnet should not conflict with the Ethernet subnet on the client
side and with the Ethernet subnet on Smart 16 IP Network side.
Modem Client IP address - This address is assigned to your console computer
during the PPP handshake. Since it is a point-to-point IP connection virtually
every IP address is possible but ensure, it is not interfering with the IP settings of
Smart 16 IP and your console computer. The default value will work in most
cases.
IPMI over Serial - Check to use this serial port for IPMI 1.5 over serial. See
page 42 for more information.
Passthrough access to serial port via Telnet - Connect an arbitrary device to the
serial port and access it (assuming it provides terminal support) via telnet. Select
the appropriate options for the serial port and use the Telnet Console (see page
37) or a standard telnet client to connect to Smart 16 IP. For more information,
see page 14.
External Power Option – When the External Power Option is the Sentry
Power Tower or Baytec RPC series connected to Serial port 1, configure it by
clicking change external power switch option. The External Power Option for
Serial port 1 window appears.
Fill in the Username and password and serial line speed as defined by the Sentry
Power Tower.
