OPERATING GUIDE
17.
KVM Settings
By default the Smart 16 IP is configured for 16 ports. When you want to add
more, adjust the settings for the KVM ports. From the Smart 16 IP menu choose
KVM Settings. The Smart 16 IP KVM settings appear. See Figure 14.
Figure 14 KVM Settings
The elements of the KVM Settings are explained below.
Active Port
To switch to a computer:
1. Choose a number in the Active port Drop-down list.
2. Press
. The computer screen appears in the Remote Console.
Number of Ports
To set the number of ports the KVM uses:
1. Choose a number in the Number of Ports Drop-down list.
2. Press
. The number of rows chosen appears in the KVM Port Settings
list. See Figure 15.
Duration of Pause
Many KVM switches require a pause between hotkey keystrokes. Add a pause for
reliable switching between KVM ports. Define the pause time for KVM and
Remote Console Button Keys in milli-seconds, represented by the * symbol in all
hotkeys and button keys.
20
