4. When prompted reset Smart 16 IP manually by pressing the
or Remote console close. 30 seconds later, Smart 16 IP runs with the new
firmware. You must login again.
Attention: Only experienced staff members or administrators should perform a
firmware update.
Direct SmartIP Links
You can set up direct links to Minicom IP hardware over a LAN or WAN.
Currently supported Minicom IP models are:
·
Smart Extender
·
Smart 16 IP
·
Phantom MXIP
·
Smart IP Link
·
DXU IP
Use the links to directly connect to these IP units without having to remember
their IP addresses. You can also see the status of the remote IP units as explained
below.
All the IP units must have firmware that supports direct connection functionality.
Ensure that firmware of all units is updated to the latest version. See the User
Guide of each IP unit to update the firmware.
To set up the direct connections:
1. Scroll down the Maintenance window to Maintenance Features. See Figure 34.
2. Click Direct SmartIP Links. The Direct Connection Links page opens.
See Figure 35.
OPERATING GUIDE
button. When pressed all connections to the administration
Figure 34 Maintenance Features
.
