Operating the Projector

Switching the Projector On

•
Connect the power cable between the mains supply and the projector. Switch on at the switch next to the power connector.
•
Wait until the self-test has completed and the Standby indicator on the projector control panel shows amber. The lamp will be off and the
projector will be in STANDBY mode.
•
Press on the control panel or
POWER
The Power indicator on the control panel will flash blue for a few seconds whilst the lamp comes up to full brightness. When the projector
is ready for use, the Power indicator will show steady blue.

Selecting an Input Signal or Test Pattern

Input signal

•
Connect an image source to the projector. The signal should be automatically detected by the projector, and should be displayed within a
two or three seconds.
•
If more than one signal is connected, then select the image you want to display:
Select from five of the inputs using
or press SOURCE on the control panel to cycle through all the inputs.
or use Source Select in the General menu

Test pattern

If you have no image source connected to the projector, then you can display a test pattern instead:
Select a Test Pattern from the General menu
Rev D July 2014
OPERATING THE PROJECTOR
on the remote control, and hold for 3 seconds.
to on the remote control,
.
.
Installation and Quick-Start Guide
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
For full details of how to connect an
image source to the projector, see
the Connection Guide.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
Page Inst_6
