Getting to Know the Projector

Front and rear views

Lens shift
controls
Front
infra-red
window
Focus
adjustment
Lens
Zoom
adjustment
Control
panel
Air
inlets
Mains
input
Connection
Rev D July 2014
GETTING TO KNOW THE PROJECTOR
Air
inlet
Rear
infra-red
window
Air
outlets
Adjustable
feet
panel

Remote control

Infra-red
reception
Installation and Quick-Start Guide
Notes
The projector uses the standard
MVision series infra-red remote
40°
control.
Some of the controls are duplicated
on the projector control panel, as
shown on the next page.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
40°
Page Inst_3
