PROJECTOR PERFORMANCE SPECIFICATIONS
Brightness (±10%)
35HD-T:
18,000 Center lumens
16,000 ANSI lumens
40HD-T:
22,000 Center lumens
21,000 ANSI lumens
Contrast Ratio (±10%)
>1600:1 full-field
Display Type (one per R, G, B)
3 x 1.26" dark metal FTP DMD™
DMD Specification
2048 x 1080 pixels native, 12° tilt angle
Fill factor
90% pixel fill factor
Sealed Optics at DMD Interface
Protects DMD's from optical contamination
Lamp Type
Proprietary xenon arc, bubble. Hyper-cooled
lamp module with directional-flow reflector
mask and radial heat exchanger.
Digital Hour meter.
Lamp Life
1
750 hours (typical)
Lens Mount
Intelligent, programmable lens functionality
Motorized horizontal and vertical lens shift,
zoom and focus. 1/4 pixel landing accuracy.
MULTI-MEDIA SWITCHER 1000 SPECIFICATIONS
Input capabilities-see table lower right
Video Processing
10-bit processing from video input to output
DigiScale - accurate image resizing for
faithful reproduction of all displayed sources
DigiView - optimized video processing,
deinterlacing and 3:2 pull-down
Edge Blending
DigiBlend - edge blending for
tiling of multiple projected images
Geometry
DigiWarp (optional) - user definable control
over all image geometry. Horizontal/vertical
and keystone warp correction for both
cylindrical and spherical displays
Specifications subject to change without notice
™DLP , Digital Light Processing and DMD are trademarks of Texas Instruments, Inc.
3 5 H D -T, 4 0 H D -T a n d M M S 1 0 0 0
Lens Shift (typical, dependent on lens)
Vertical: ± 0.25-0.5 frame
Horizontal: ± 0.1-0.25 frame
Lens Options
1.8-2.4
1.0
:1 fixed
1.25-1.45:1 zoom
2.2-3.0
1.45-1.8 :1 zoom
3.0-4.3
Control
Rear touch screen with "ShowMode"
diagnostics - provides direct control and
feedback over projector functions.
Wireless LAN "802.11b", LAN and RS232
Mechanical Mounting
Floor or ceiling, front or rear. Integrated
handles and rigging frame with pitch and roll
adjustments, flexible stacking/rigging points.
Rugged, stager tolerant chassis
Orientation
360˚ front to back
±15˚ left to right
Dimensions (excludes feet)
43.4in(L) x 28.4in(W) x 18.7in(H)
1103mm(L) x 721mm(W) x 475mm(H)
Weight (chassis only)
249lbs (113kg)
Interface To Projector Via DigiLink
High-bandwidth digital link extendable
by rugged fibre optic cable providing
optically-isolated interconnection -
offering significant benefit to staging
and installation customers by reducing
cable complexity and signal interference
due to grounding
Control
Front panel LCD, IR/Hardwired remote
control, external control via RS232/422,
USB or LAN
PC Card Slot
Wireless LAN, data download
Dimensions
Five RU 19" rack mountable
17.7in(L) x 19in(W) x 8.7in(H)
450mm(L) x 483mm(W) x 221mm(H)
DP V1.06/06 ©2006 Digital Projection, Inc.
Digital Projection International, the original innovator
of the 3-chip DLP™ projector, proudly introduces the
LIGHTNING 40HD-T & 35HD-T Pro Series Displays.
The HD-T series carries forward all of the benefits
of the Professional Series LIGHTNING Chassis -
exceptional rigging and stacking hardware with
integrated pitch and roll adjustments - while also
delivering the enhanced benefits of active 3D
capability, extended color depth and improved
lumen maintenance.
Additional benefits of the LIGHTNING 40HD-T/35HD-T
include:
• Active 3D compatibility up to 2K resolution
• Accepts sources up to 12 bits per color
(R, G & B) through twin-dual DVI input.
• Sealed optics to protect DMD's and other focal
:1 zoom
plane components from airborne contaminants
:1 zoom
• DPI's new, hyper-cooled lamp module with
:1 zoom
digital hour meter, dramatically improves
projector thermal characteristics and extends
reflector life and lumen maintenance.
When paired with the MMS 1000, the LIGHTNING
HD-T can support extensive video, HD or computer
sources. The rack-mountable system includes
DigiLink, a single-link DVI and twin-link DVI ultra-high
bandwidth digital output to the projector, simplifying
system wiring and reducing installation costs. The
MMS 1000 also includes soft-edge blend and can
be configured to incorporate options such as
seamless switching and geometric warp.
The new LIGHTNING 40HD-T & 35HD-T - ultra
powerful, immensely capable displays for visual-
ization, major events and color-critical applica-
tions - bringing the precision of Digital Projection,
to the world's most demanding venues.
INPUT CAPABILITIES
Type
Projector input:
Single DVI wth loop through
(receives up to 8 bits per color (R,G,B) at up to 2048x1080 at 60Hz)
Twin Dual DVI - MAIN + SUB
(receives up to 12 bits per color (R,G,B) at up to 2048x1080 at 110Hz)
MMS 1000 input/output:
Four available input slots:
standard modules:
Composite / component video /
S-video input module (mm-video)
RGB HV / component input
module (MM-RGB)
optional modules:
DVI-D input module (MM-DVI)
SD-SDI / HD-SDI input module
(MM-SDI)
Output:
DigiLink
1 Input selection is automatic but is prioritised to the MAIN+SUB input.
Selection is by detection of DVI signal.
2 See MMS 1000 user manual for detailed input specifications
Connector
1
DVI-D
DVI-Dx2
2
BNCx1,BNCx3,
4-pin mini DIN
BNCx5
DVI-D
BNCx2
DVI-D
Quantity
1
1
1 each
1
1
1
1
