Electrical Connections

Please ensure the following are available and have been tested prior to the installation:
• Mains point
• Network point
• Network cable
• Active video signals i.e. at least one working camera feed
• PC with CD ROM drive and connection to the same network as the NVR (Recommended).

Quick Overview of SD Excel Record Settings

The SD Excel provides as default:
Consistent recording duration and smooth motion video per camera regardless of the number of cameras.
Default record settings at MPEG4 6.25pps (at 2CIF), JPEG 3pps (at 2CIF) and MultiMode recording at
MPEG4 6.25pps (at 2CIF), JPEG 6.25pps (at 2CIF).
Complete Flexibility
The advanced record menu can be used to configure individual cameras to suit specific requirements
e.g. Entry/Exit routes. Various storage sizes are available dependent on the combination of the number of
cameras, the storage options and record rates selected.
Recording
MultiMode
The unit supports MultiMode recording, which is a storage technology developed by Dedicated Micros.
This offers the ability to set different recording rates, resolutions and compression formats across
scheduled, normal and alarm modes for each individual camera.
By varying the quality, bit rate and file size of the recorded images, the MultiMode function can increase
recording capabilities of the unit.
MultiMode offers:
Ability to set different recording resolutions.
Ability to set and switch MPEG or JPEG compression recording as required.
Ability to set PPS recording rate per camera.
Dynamically switchable resolution when switching from Normal to Event recording.
Dynamically switchable compression between MPEG4 and JPEG from Normal to
Event recording.
