Dedicated Micros SD Excel Installation Manual page 48

Disable Transcoding
Partial Full Duplex
Segment Aspect Ratio
Note: There is no cropping or distortion on the recorded image, these settings are for display only.
System (Red)
Network (Green)
Video (Yellow)
Other (Blue)
Refresh (Purple)
48
Select to disable the unit's transcoding capabilities. In normal
circumstances this should always remain enabled, however it can be
useful to disable the feature when conducting maintenance.
Select to enable the Partial Full Duplex option. This feature is only
relevant when viewing in mulitiscreen mode above quad. When
selected (and viewing in MPEG mode/multiscreen above quad); only
the recorded I frames are displayed and not the P
frame data.
This setting control how a 4:3 image is displayed in a multi-screen or
wide screen format on the local viewer. The available display segment
changes depending on the number of multi screen images selected for
display.
Stretch forces the image to fill the available display segment. This may
result in some distortion of the display image.
Zoom Fit forces the frame to fill the available segment completely and
proportionally. Consequently some of the image at the top and bottom
of the frame may be cropped.
Frame Fit forces the frame to fill the available segment proportionally,
resulting in black bars left and right on some multi display choices.
Select to open the System->Features->System page
Select to open the System->Features->Network page
Select to open the System->Features->Video page
Select to open the System->Features->Other page
Refreshes the information on the current page
