Unset/Set/Override Event
Note: When Turbo mode is selected, there will be only ONE configurable Record Profile across ALL
cameras. The unit then matches the live transmission rate to the configured record rate. This
enables a 'doubling' of performance. Only the 'Low' and 'Medium' Live Transmission profiles
are available for configuration (Network Settings->Live Transmissions). Low and Medium
transmission settings are configurable to allow video streaming over low bandwith IP connections
and are limited to CIF for this purpose.
Note:
Unset, Set and Override modes can be given more recognisable titles i.e. Day, Night, Weekend
via the Schedule menu (Record Settings->Schedule).
Comp
PPS
Quality
Note: The higher the Quality setting, the greater the storage space used.
Codec Load (Red)
Refresh (Purple)
Shows the recording quality that will be used by the camera during an
Alarm or Event. Note that Set and Override schedules will be used only
when Timed Schedules are applied. Refer to the 'Schedules' section for
further details.
Select image compression format (MPEG, JPEG).
The accompanying dropdown list allows the number of frames captured
per second to be set.
The pictures per second (pps) option allows either 6, 5, 2, 1, 0.5, 0.25
or 0.1 pps to be recorded.
Pictures can also be recorded at 'Real Time' speed, '3/4 Real Time' or
'1/2 Real Time'.
To disable record, choose the 'No Record' option.
Select 'User Defined' to use settings established in the Advanced
Profile Record menu.
The accompanying dropdown list allows the quality of recorded images
to be set. Select from Maximum, Very High, High, Medium, or Low.
Select User Defined to use settings established in the Advance Profile
Record menu.
Select to open the System->Status->About->Codec Loading page
Refreshes the information on the current page.
