  • Page 1 EcoSense Installation & Operation Guide...

  • Page 2: Table Of Contents

    Appendix D ..............114 Appendix E ............... 115 Whilst every attempt is made to ensure these manuals are accurate and current, Dedicated Micros reserve the right to alter or modify the specification of the machine described herein without prejudice. Dedicated Micros ©2009...

  • Page 3: Introduction

    The EcoSense offers a global record rate of up to 200pps (dependant on model) at CIF and can record up to 16 cameras (dependant on model) simultaneously in MPEG-4 or JPEG format. The Profile Record feature enables an operator to set different recording rates and resolutions across scheduled, normal and alarm modes for all cameras.

  • Page 4: Features

    The unit has NetVu Connected technology built-in to ensure maximum compatibility with future developments in networked security. NetVu Connected technology enables the Unit to fully interact with other NetVu Connected compatible products from Dedicated Micros including the DV-IP Decoder, NetVu ObserVer and PDA Viewers. Providing interoperability between the worlds leading security companies, NetVu Connected uses industry standard networking protocols supported by a wide range of third party integration products and SDKs to ensure future on-going compatibility.

  • Page 5: Design Of The Manual

    The order and layout of these pages has been designed to help the setup process. It is recommended that the menus are edited sequentially (as they appear on the page), to enable accurate, easy and efficient setup. Dedicated Micros ©2009...

  • Page 6: Important Safeguards

    This reminder is provided to call the CCTV system installer’s attention to Art. 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical. Dedicated Micros ©2009...
  • Page 7 CE Mark If this product is marked with the CE symbol it indicates compliance with all applicable directives. Directive 89/336/EEC. A ‘Declaration of Conformity’ is held at Dedicated Micros Ltd., 1200 Daresbury Park, Daresbury, Cheshire, WA4 4HS, UK. Laser The unit supports an integrated CD writer, the following are additional warnings associated with installing and operating the CD writer, please pay particular attention to this information.

  • Page 8: Installing The Unit

    EcoSense Software CD • Quick Start Guide If any of these items are missing please contact Dedicated Micros Technical Support team. Note: Before installing the unit, carefully read all Safety Instructions and the following information on where the unit should be located.

  • Page 9: Quick Overview Of Default Record Settings

    3pps on each camera, out of the box, at a record duration of 7, 14 or 30 days (the default is 14 days). Note: It is the Installer/Owner’s responsibility to ensure that the record duration is set to the necessary requirements of the application. Dedicated Micros ©2009...

  • Page 10: Installation

    Installation Front Panel connections Data CD/DVR Internal CD/DVR drive USB2.0 connector Infra-Red receiver for use with Remote Control Rear Panel connections 16 Input model 8 Input model 4 Input model Dedicated Micros ©2009...

  • Page 11: Alarms And Relays

    Via 25 way (female) D Type rated at 24V 200mA 2 onboard light duty relay output (500mA@12V-48V Max) Note: 1 relay output supported on 4 channel unit. Power POWER input for 12v DC external power unit (supplied). Dedicated Micros ©2009...

  • Page 12: Installing The Ecosense Unit

    Installing the EcoSense Unit This procedure shows the sixteen camera input version. Step 1 Connecting Video The unit supports up to 4, 8 or 16 connected Video Inputs (dependant on model) via the 75Ω BNC connectors. Connect cameras to the video inputs, starting from input 1.
  • Page 13 IP address can change without notification i.e. following power failure. It is therefore recommended that the unit be allocated a fixed IP address. A fixed IP address can be assigned via the Configuration Menu pages:Network Settings->Network->IP Address. Dedicated Micros ©2009...
  • Page 14 The unit supports 17 normally open/closed alarm inputs via the back panel, or one Global keyswitch input with camera specific inputs configurable as entry/exit alarms. Note: The 4 channel unit supports 5 normally open/closed alarm inputs. Relay Connector Alarm Input Connection 1 - 17 1-17 18-21 Earth Common Dedicated Micros ©2009...

  • Page 15: Relay Connector

    KBD connector socket on the rear panel. Note: The optional Keyboard is not supported on the 4 channel unit. Note: Refer to the Unit Operation section of this manual for further guidance regarding the supported keyboards. Dedicated Micros ©2009...
  • Page 16 Connect the 12v DC power adaptor (supplied) to the unit and then to the wall socket, or to a fused spur connection. To be compliant with wiring regulations in some countries, an Alarm/ Security device should be connected to a fused spur and not a wall outlet socket (check local regulations before installation). Dedicated Micros ©2009...

  • Page 17: Accessing & Configuring The Unit

    The default DNS address can be renamed via the Network Settings->Network menu. Following renaming, the DNS address will be: yourname.yourdomain.com • ’ yourname‘ is the name assigned via the Network menu. • <yourdomain> is the name assigned to your DNS network Dedicated Micros ©2009...

  • Page 18: Accessing The Configuration Webpages

    Accessing the Configuration Webpages The unit can be configured using the webpages. To access these: Launch Internet Explorer (or similar web browser package). Type the URL for the unit (IP or DNS address). The Opening menu page will be displayed. Dedicated Micros ©2009...

  • Page 19: Remote Control

    This button should be pressed (followed by a numeric entry) to carry out auxiliary actions on a PTZ camera. Press the Menu button to enter the Configuration menus. Press the Exit button to exit the Configuration menus. Dedicated Micros ©2009...
  • Page 20 The Number pad should be used to select specific cameras and preset positions when available. Use the Playback buttons to interrogate recorded images. Use the LIVE button to switch from Playback or menus to a LIVE display. Dedicated Micros ©2009...

  • Page 21: Using The Ir Remote Control

    The cursor will then progress, ready for the next character entry. Note: A USB Keyboard (not supplied) can be connected via one of the USB ports on the unit. The USB Keyboard can then be used to enter alpha-numeric data via the local menus. Dedicated Micros ©2009...

  • Page 22: Using A Usb Mouse Or The Webpages

    Using a Supported Dedicated Micros Keyboards (DM/KBC1 & DM/KBC2) The unit can also be controlled using an optional Dedicated Micros keyboard (except the 4 way unit). This is connected via the KBD connector on the rear of the unit and provides the same control functions as the I.R Remote Control.

  • Page 23: Main Menu

    ObserVer Manual Select to open an electronic version of the NetVu ObserVer User Guide. NetVu ObserVer is a free video management software package from Dedicated Micros. It allows users to seamlessly view distributed images from any ‘NetVu Connected’ product. •...

  • Page 24: Navigating The Configuration Menus

    PC mouse (if viewing the webpages). Note: Any changes made via the webpages are automatically saved when the page is closed. To ‘manually’ save changes, select the Save option. Dedicated Micros ©2009...

  • Page 25: System Settings

    Email reporting, webcam support and control of the display resolution. The Maintain page allows the current configuration to be saved, and for previously saved settings to be loaded. It also enables easy upgrade of the system software. Dedicated Micros ©2009...
  • Page 26 Displays the video standard adopted by the unit i.e. PAL, NTSC. MAC Address This is the MAC address assigned to the unit. IP Address This is the IP address allocated to the unit. Sub Net This is the subnet of the network where the unit is located. Dedicated Micros ©2009...
  • Page 27 This identifies the codec version the unit is running. Webpage Revision This identifies the webpage version the unit is running. PC Apps Revision This identifies the revision archive of the Viewer and associated PC Apps software. Boot Software Rev. Displays the infrastructure componentry software revision. Dedicated Micros ©2009...

  • Page 28: Unit Status

    Framestores Installed codecs currently operating as a framestore will be highlighted light green. Hover the cursor over individual buttons to display either ‘On’ or ‘Off’. ‘On’ signifies that the codec is active as a framestore. Dedicated Micros ©2009...
  • Page 29 Those camera channels with cameras connected will be highlighted light green. Those not in use will appear dark green. Failed Cameras Those camera channels where the connection is deemed to have failed will be highlighted light green. Those working correctly will appear dark green. Dedicated Micros ©2009...

  • Page 30: Alarm Status

    This menu details information regarding the status of the unit’s alarm contacts, alarm zones and relay outputs. Alarm Contacts/Zones/Relay Outputs Alarm Contacts, Alarm Zones and Relay Outputs that are in an ‘active’ state are shown light green. ‘In-active’ ones appear dark green (not illuminated). Dedicated Micros ©2009...
  • Page 31 Select to reset the unit. Note: The unit MUST be reset to implement system language changes. Session Language Select to change the language settings for the current session only. Choose Select to immediately activate session language changes. Dedicated Micros ©2009...

  • Page 32: Time And Date

    Use this button to synchronise the time of the unit to that of the PC being used to view the webpages. Note: The PC Time and Sync Time options will only be available if viewing the menu via the webpages. Dedicated Micros ©2009...

  • Page 33: Serial Ports

    Note: When a telemetry protocol is selected, these settings will default to pre-determined values and should not normally be altered. Protocol This is a drop down list of serial telemetry protocols supported by the unit. Note: Refer to ‘Appendix E’ for a full list of supported telemetry protocols. Dedicated Micros ©2009...
  • Page 34 Select this option to activate the AGC (Automatic Gain Control) function. AGC helps produce a better quality recording by removing background noise/distortion. Record uncompressed Select this option to record audio in an uncompressed format. Note: Recording in uncompressed format will significantly increase the disk space used. Dedicated Micros ©2009...
  • Page 35 If the default port setting for web serving has already been allocated, it is possible to configure a second port number i.e. the secondary web port can be set to 8000 if the default web port (80) is blocked by the network or firewall. Dedicated Micros ©2009...
  • Page 36 Auto Update Web Variables Configures the unit to update all system variables required for an automatic upgrade without requiring confirmation. Do not check this box if you run a customised applet. Dedicated Micros ©2009...
  • Page 37 Select to cycle the power to the unit. IMPORTANT: To upgrade the unit, insert a media device containing relevant software upgrades and select ‘Reset‘. Note: For the latest software upgrades, please refer to the Dedicated Micros website: www.dedicatedmicros.com Dedicated Micros ©2009...

  • Page 38: Display Settings

    Main or Spot monitors, the colour of that text, and how long cameras being displayed in sequence will be shown on screen. The User Accounts page helps protect configuration procedures by limiting access to specific users via accounts and passwords. Dedicated Micros ©2009...

  • Page 39: Viewer Defaults

    Select the display output that best suits the viewing monitor. Select from: PAL Default PAL Reduced Note: It will be necessary to reboot the unit to implement any change to the Video Output Mode. The unit can be rebooted via System Settings:>Maintain:>Reset. Dedicated Micros ©2009...
  • Page 40 For example, if a local unit and a remote DVR are to be accessed, it is possible to set the Applet location for both DVRs as the local unit. If viewing the unit remotely, Dedicated Micros provide a remote applet located on the Dedicated Micros website (www.dedicatedmicros.
  • Page 41 Spot Sequence Setup All of the unit’s camera input channels are shown. To include any of these camera channels in the spot monitor sequence, selected the accompanying tickbox. Dedicated Micros ©2009...

  • Page 42: User Accounts

    Assigning username and password requirements for Telnet connections will limit Telnet access to the unit (Telnet can be used to upgrade the unit). • Serial Assigning username and password requirements for Serial connections will limit access via a Serial link. Dedicated Micros ©2009...
  • Page 43 Modify or Delete. Note: If viewing the User Accounts page via a local monitor and navigating with the I.R Remote Control. Press the right directional button from the menu tree to access the Account List. Dedicated Micros ©2009...

  • Page 44: Camera Settings

    The Camera page allows the quick configuration of all connected local camera channels. The Camera Setup page allows the colour and contrast settings for each individual camera to be adjusted (with a dynamic preview available). The Camera Telemetry page enables telemetry capable cameras to be configured. Dedicated Micros ©2009...
  • Page 45 Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Mode arrow will replicate the Mode setting to all cameras below the clicked arrow. Dedicated Micros ©2009...

  • Page 46: Camera Setup

    Select a colour value from -8 to +8 via the slidebar or enter a number directly into the accompanying textbox. Camera Contrast Select a contrast value from -8 to +8 via the slidebar or enter a number directly into the accompanying textbox. Dedicated Micros ©2009...

  • Page 47: Camera Telemetry

    Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Telemetry arrow will replicate the Telemetry setting for all cameras below the clicked arrow Dedicated Micros ©2009...

  • Page 48: Record Settings

    The Holiday and Weekend page enables Set mode to be activated for individual dates i.e. public holidays or weekends. The Protect Video page allows previously recorded data to be protected and retained. If needed, all recording can be halted and saved video deleted. Dedicated Micros ©2009...
  • Page 49 Select from Normal Rate MPEG4 5pps or Normal Rate JPEG 1pps Record Duration/Enhance Quality The recording duration can be limited to a set number of days (30,14 or 7); allowing the recording quality to be enhanced for a shorter storage period. Dedicated Micros ©2009...

  • Page 50: Profile Record

    Enables selection of a specific camera for editing. Copy To All Select to copy the current profile record settings to all camera channels. Copy To Next Select to copy the current profile record settings to the next camera channel. Dedicated Micros ©2009...
  • Page 51 The accompanying dropdown list allows the quality of recorded images to be set. Select from Maximum, High, Medium, Low or Very Low. ‘User Defined’ is for future use. Note: The higher the Quality setting, the greater the storage space used. Dedicated Micros ©2009...
  • Page 52 Note: When the Keyswitch option is set to ‘Enabled’. It is necessary to save (or exit and return to) the menu. The additional Keyswitch options will then be displayed. Enable-N/O Select if the Keyswitch is to be normally open (UNSET). Then choose a contact to be used in a specific zone as the Keyswitch. Dedicated Micros ©2009...
  • Page 53 (EOL) option enables the Keyswitch to detect any changes in the electronic input resistance. A change outside the expected values will result in a Tamper Alarm (short circuit or open circuit) being detected and the system switching to alarm mode. Dedicated Micros ©2009...

  • Page 54: Holiday & Weekend

    Start Select a Start day and time for Weekend mode. Select an End day and time for Weekend mode. Note: Weekend mode will remain activate each week until deselected. Dedicated Micros ©2009...

  • Page 55: Protect Video

    This will refresh the video list according to the selections made in the Start Time/Date and End Time/Date dialog boxes. Select None This de-selects all the available video files. Select All This selects all the available video files. Dedicated Micros ©2009...
  • Page 56 This dialog box allows a search to be made within the protected video list starting from a specific Time and Date. List To Date/Time This dialog box allows a search within the protected video list to conclude at a specific Time and Date. Dedicated Micros ©2009...

  • Page 57: Alarm Settings

    This can trigger a number of operations such as FTP alarm notification or an increase in the recording rate. The Activity Response page enables configuration of responses following an Activity Detection trigger. The Global Relays page allows the four onboard relay connections and global relay settings to be configured. Dedicated Micros ©2009...

  • Page 58: Alarm Input

    Enter the time in seconds for this extension. Dedicated Micros ©2009...
  • Page 59 Note: The arrow button displayed next to each textbox allows settings to be replicated for those cameras listed below. This will only affect the adjacent option i.e. Enabled arrow will replicate the Enabled setting to cameras below the clicked arrow. Dedicated Micros ©2009...

  • Page 60: Zone Input

    Note: It is recommended that the Pre-Alarm option be set to the same value as the Pre-Trigger setting in the “Profile Record“ menu. This will ensure successful playback of high quality Pre-Trigger images. High quality pre-trigger images will only playback properly if review (playback) starts prior to the pre-trigger initiation. Dedicated Micros ©2009...
  • Page 61 Set operation mode. Enable in Override Each alarm can be configured to be active when the unit is in a specific operation mode. Enable this for the zone alarm to be active in Override operation mode. Dedicated Micros ©2009...

  • Page 62: Zone Actions

    It is possible to play associated audio upon zone alarm activation. Alarm Reporting This must be enabled to allow the unit to send an alarm notification to an external destination i.e an RVRC reporting via NetVu ObserVer. Dedicated Micros ©2009...
  • Page 63 Alarm Image Snapshot Delay This figure allows a delay to be introduced before an alarm snapshot is taken. This is used when the alarm relates to a PTZ camera which has to travel to a preset position. Dedicated Micros ©2009...

  • Page 64: Activity Setup

    OK button. If viewing via the webpages, use the mouse to navigate across the image, use the left mouse button to place a cell. Reload Img (Red) This option will update the still image displayed in the Grid Editor. Dedicated Micros ©2009...
  • Page 65 Select ‘Clear’ to remove grids or select ‘Set’ to add grids. Activity Sensitivity This option allows the sensitivity setting to be established for the activity grid being configured. There are five settings to choose from: Indoor High, Indoor Low, Outdoor High, Outdoor Low, Very Low. Dedicated Micros ©2009...

  • Page 66: Activity Response Setup

    This will ensure that Activity Detection is permanently enabled on this camera channel. Add Still Image This will record a still image of the trigger along with the standard recording. This can then be sent on to an external destination. Dedicated Micros ©2009...
  • Page 67 This will enable Activity Detection when the unit is in Day (Unset) operation mode. Enable in Night This will enable Activity Detection when the unit is in Night (Set) operation mode. Enable in Weekend This will enable Activity Detection when the unit is in Weekend (Override) operation mode. Dedicated Micros ©2009...

  • Page 68: Global Actions

    Therefore the relay will close when an alarm is received on any of the alarm inputs. Activity (Relay 2) Select this option to establish any Activity Detection trigger as a Global Relay. Therefore the relay will close when Activity is identified on any of the camera inputs. Dedicated Micros ©2009...

  • Page 69: Network Settings

    SMTP Server following an event i.e. on receipt of an alarm or a camera failure notice. The FTP Download page allows data to be archived to a central FTP server. This could be on receipt of an alarm, Activity activation or at a scheduled time to back-up recorded video. Dedicated Micros ©2009...
  • Page 70 MTU is the largest physical packet size measured in bytes that the network can transmit. By default this figure is set to 1500bytes. Mx Transmission Timeout ms This is the time (in milliseconds) the unit will wait to re-send a packet if an acknowledgement is not received. Dedicated Micros ©2009...
  • Page 71 PPP (Point to Point Protocol) link if data has not been transmitted or received. PPP Link Down Timer mins If for any reason the PPP connection is lost, this is the time (in minutes) before the unit will be forced to drop the PPP connection. Dedicated Micros ©2009...

  • Page 72: Live Transmissions

    On MPEG transmission, increasing the pictures sent will also reduce the quality of the images (as more images are transmitted for the defined bit rate). Dedicated Micros ©2009...
  • Page 73 I frame and then a sequence of P frames (until a change in transmission is detected). GOV mode sends I and P frames in a standard format i.e. I to P frame ratio as set by the record parameters. Dedicated Micros ©2009...

  • Page 74: E Mail

    This is the ‘reply to’ name that will be shown in the email name field. Sender Email These optional fields indicate the source of the e-mail notification. If the fields are left blank the unit will use the system name to create a sender name. Dedicated Micros ©2009...
  • Page 75 Log Email Select to log every e-mail transaction that the unit issues. Email Image Res Select resolution settings for images sent as ‘thumbnail’ attachments. Choose from: Thumbnail, LO (low res), MED (medium res) and HI (high res). Dedicated Micros ©2009...

  • Page 76: Ftp Download

    If it is necessary to use an authentication process to access the FTP server, enter the relevant username here. Password If it is necessary to use an authentication process to access the FTP server, enter the relevant password here. Dedicated Micros ©2009...
  • Page 77 FTP download overrides Powermanager When selected, if the unit is in the process of an FTP download and the unit is sent into reset, the reset will not begin under the FTP process has completed. Dedicated Micros ©2009...
  • Page 78 Space required for archive download. Archive Space Available Space currently available on CD/DVD or USB device. Archive button Select this button to begin the Archive process. Status During Archiving, status messages will be displayed detailing the archive process. Dedicated Micros ©2009...

  • Page 79: Oracle Dome Configuration

    Oracle Dome Configuration If a camera channel has a Dedicated Micros Oracle dome camera connected, the Oracle Configuration menus can be used to view settings and establish Presets, Patrols and Privacy Masks. Refer to individual menus for further details. The Status page details fundamental information regarding the status of the Oracle Dome i.e. the model type and the version of software/firmware installed.
  • Page 80 Details the minimum temperature the camera unit has reached. Fan 1 Status Details the operational status of installed Fan 1. Fan 2 Status Details the operational status of installed Fan 2. Relay State Details the operational status of the camera unit’s relay. Dedicated Micros ©2009...
  • Page 81 This identifies the version of software the camera unit is running. Firmware Version This identifies the version of firmware the camera unit is running. Bootloader Version This identifies the bootloader version of the camera unit is running. Dedicated Micros ©2009...
  • Page 82 Select this button to store the current preset position to the Oracle Dome camera’s memory. Goto Preset (Green) Select this button to immediately send the camera to the currently stored preset position. Delete Preset (Yellow) Select this button to delete the currently displayed preset configuration. Dedicated Micros ©2009...
  • Page 83 25 characters). + (Red) Use the + button to zoom the camera view IN. - (Blue) Use the - button to zoom the camera view OUT. Navigation Buttons Use the four navigation buttons to position the camera view. Dedicated Micros ©2009...
  • Page 84 Select the Dwell time (in seconds) the Patrol will remain at this Preset position. Save (Grey) Select to store the preset sequence to the unit and the Oracle Dome camera memory. Play (Red) Select to activate (play) the current patrol sequence. Dedicated Micros ©2009...

  • Page 85: Privacy Masks

    Privacy Mask. Save (Grey) Select to store the mask colour. Start New (Red) Select this option to begin creation of privacy mask. Finish New (Green) Select this option to finish creation of privacy mask. Dedicated Micros ©2009...
  • Page 86 Show (Yellow) Select this option to show camera view with existing privacy mask displayed. Delete (Blue) Select this option to delete the currently displayed privacy mask. Dedicated Micros ©2009...

  • Page 87: Osd Settings

    ‘stacked’ in one segment of the screen. Engineer Display Toggle to switch the Engineer Display text On/Off. This function is intended for future development. Save (Grey) Select to store OSD Settings to the unit and the Oracle Dome camera memory. Dedicated Micros ©2009...
  • Page 88 180 degrees and begin tilting down. If unselected, a camera will stop when it reaches its maximum upper or lower extremity. HyperD Mode If the connected Oracle Dome camera is part of the HyperD non-wide dynamic range, select to activate the unique wide dynamic function. Dedicated Micros ©2009...
  • Page 89 1 and 100 until the optimum image quality is reached. UTP Boost If the camera feed to the unit originates from the twisted pair output of the camera. Two levels of boost can be activated to improve image quality by compensating for losses in the cables. Dedicated Micros ©2009...

  • Page 90: Event Settings

    Select the time ( in seconds) for which the camera is inactive i.e. no operator input, before returning to its home position. Save (Grey) Select to store Event Settings to the unit and the Oracle Dome camera memory. Dedicated Micros ©2009...

  • Page 91: Unit Operation

    The function of the keys will change according to whether the unit is in Live or Playback mode. Overleaf are described the available Viewer menu pages. To display the colour coded menu options when viewing locally, press the OK button on the IR Remote Control or click the mouse button. Dedicated Micros ©2009...

  • Page 92: View Control

    2 top left, cam 3 adjacent etc. Note: The Multi option not available on 4-way model. Blue Help Select to display the Video Help menu. Purple Next Opens the next page of the Viewer menu. Dedicated Micros ©2009...

  • Page 93: Video Control

    The Video Control page offers video playback functions i.e. play, pause, rewind and fast forward. Freezes current video display. Green << Rewinds current video. Yellow > Plays from current position. Blue >> Fast forwards video up to current recording position. Purple Next Opens the next page of the Viewer menu. Dedicated Micros ©2009...

  • Page 94: Selection Page

    Activity Log as the current user terminating the session, refer to ‘Appendix C’ for further information regarding the User Activity Log. Purple Next Opens the next page of the Viewer menu. Menu will be displayed in the local viewer, Setup will be displayed in the remote viewer. Dedicated Micros ©2009...

  • Page 95: Ptz Program Option

    Patrol option and enter a number. Refer to the ‘Patrols’ menu page for further details on establishing Patrols. Blue Prog Opens the ‘Dome Menu Option’ page. Purple Next Opens the next page of the Viewer menu. Dedicated Micros ©2009...

  • Page 96: Program Page

    Any command that sends the camera to a coordinate will use this origin as its starting point.. Note: This option is only available for Oracle dome cameras. Purple Back Return to the ‘PTZ Program Option’ page. Dedicated Micros ©2009...

  • Page 97: Dome Menu Option

    (dependent on the protocol selected). Please refer to the specific camera documentation for further guidance. Blue Menu Exit This option will fully exit any embedded camera sub-menus currently being viewed. Purple Back Return to the previous page of the Viewer menu. Dedicated Micros ©2009...

  • Page 98: Goto Option

    Time and Date options to view recorded images from the camera channel currently being viewed. Time Enter the required time (using the 24hr clock) Date Enter the required date Earliest Recording The earliest recording time available for the camera currently being viewed will be displayed. Dedicated Micros ©2009...

  • Page 99: Event List

    Blue When a start and end date/time parameter has been entered, select Search (blue) to begin the filter process (see Viewer menus->Event Search Filter for further details). Back Purple Select to return to the View menu page. Dedicated Micros ©2009...

  • Page 100: Event Search Filter

    Yellow System Select to only display System category events. Blue Search When a start and end date/time parameters have been entered, select Search (blue) to begin the filter process. Purple Back Return to the ‘Event List’ page. Dedicated Micros ©2009...

  • Page 101: Archive Selection

    Copy Event List. Yellow Archive Opens the Copy Menu. Blue Seq On/Off Select ‘Seq On’ to display images from all connected cameras in a sequential order. Purple Next Opens the Play menu for the currently displayed camera. Dedicated Micros ©2009...

  • Page 102: Copy Menu

    Displays the space (as a percentage) that will remain following the download. Status Displays messages relevant to the archive process i.e. ‘Archive In Progress’. Progress Displays the progress of the current archive (as a percentage of completion). Dedicated Micros ©2009...
  • Page 103 Select CD/DVD from the Archive Media checkbox. Select the Copy option (Red) to start archive. Selected items are then saved to the CD/DVD. The CD/DVD export status is displayed as a %. On completion the status will read ‘Archive Complete’. Dedicated Micros ©2009...
  • Page 104 Select ‘Seg’ to exit when all segments have been assigned a camera channel. When accessing Quad or Multiscreen display, the custom display config will now be displayed. Purple Next Opens the next page of the Viewer menus. Dedicated Micros ©2009...

  • Page 105: Help Videos

    The Help Videos offer step by step guidance on performing some of the most common tasks required of the EcoSense. Access the Video Help menu by selecting the Help (yellow) option on the View Menu. The Help videos are divided into six categories; each category containing relevant videos.

  • Page 106: Kbc1 & Dm/Kbc

    Using the optional Keyboards (DM/ KBC1 & DM/KBC2) The unit can also be controlled using an optional Dedicated Micros keyboard. This is connected via the KBD connector on the rear of the unit and provides the same control functions as the I.R Remote Control.

  • Page 107: Key Function

    Live mode - Freezes the current display window Play mode - Pauses video in playback. Live mode - puts the unit into playback using the last stored playback time Displays the Events list menu. Opens the GOTO menu Dedicated Micros ©2009...
  • Page 108 Switches on the lamp on a telemetry camera. Adjusts the focus to objects nearer the camera. Adjusts the focus to objects further from the camera. Closes the Iris on a Telemetry camera. Opens the Iris on a Telemetry camera. Dedicated Micros ©2009...
  • Page 109 Used as menu and on-screen navigation keys. Pan and tilt control for telemetry cameras. In Play mode: Used to Mark Start/End positions. ln Live mode: Displays the Copy List and archive controls. Exits menus. Dedicated Micros ©2009...

  • Page 110: Appendix A

    It is possible to connect a variety of telemetry cameras to the unit, use the following tables as a guide. RS Connectivity (Serial 1) Description Receive Data Transmit Data Ground RS Connectivity ( wire) (Serial ) Description RS485 + (A) RS485 - (B) Shield (GND) Dedicated Micros ©2009...

  • Page 111: Appendix B

    Bang & Olufsen 2000 Bauer 2617 Beko 2007/2027/2052/2180/2191/2228/2242/2269/2498/2588/2589/2616/2637 Binatone 2003 Blaukpunkt 2008/2079/2519/2625 /2636 Brandt 2029/2033/2034/2075/2076/2081/2117/2174/2272/2332/2535/2536 Brother 2610 Daewoo 2003/2009/2037/2039/2060/2070/2105/2128/2148/2224/2492/2498/2521/2551/25 65/2566/2570/2592/2605/2609/2633/2636 Ferguson 2028/2029/2036/2038/2050/2068/2076/2089/2093/2143/2173/2517/2518/2536/25 60/2618/2619/2620/2625/2627/2637 Goldline 2498 Goldstar 2003/2009/2011/2037/2053/2059/2077/2093/2094/2492/2498/2527/2542/2605/26 08/2616/2624/2629/2632/2636/2637 Goodmans 2002/2004/2009/2021/2022/2037/2045/2059/2068/2070/2076/2093/2259/23 69/2492/2496/2497/2498/2504/2516/2548/2551/2554 2605/2609/2610/2614/ 2633/2635/2636 Hitachi 2003/2004/2014/2017/2021/2026/2031/2033/2034/2035/2054/2081/2082/2083/21 69/2175/2199/2201/2202/ 2253/2260/2380/2385/2396/2414/2426/2427/2441/2448 /2450/2469/2470/2471/2472/2497/2498/2499/2500/2504/2509/2512/2522/2524/25 49/2551/2575/579/608/620/627/629/636 Dedicated Micros ©2009...
  • Page 112 8573/604/623/624 /627/629/ 635 /636/637/643/644 Pioneer 2029/2037/2081 /2093/2379/2382/2387/2390/2392/2444/2449/2498/2584/2627/26 /2637 Sanyo 2003/2004/2006/2014/2016/2021/2023/2024/2025/2030/2032/2076/2088/2161/22 20/2223/2290/2292/2401/2442/2443/2492/2494/2497/2501/2504/2513/2532/2605/ 2627/2629/2633 Sharp 2001/2005/2023/2040/2101/2102/2127/2139/2160/2162/2186/2193/2207/2219/23 35/2352/2354/2360/2365/2366/2368/2372/2373/2376/2403/2407/2417/2422/2423 /2424/2430/2431/2432/2433/2434/2455/2456/2457/2458/2459/2460/2461/2462/24 63/2483/497/502/506/513/533 Sony 2004/2009/2021/2023/2024/2047/2067/2076/2078/2091/2097/2098/2110/21 11/2118/2121/2125/2135 /2142/2166/2177/2185/2204/2234/2236/2326/2344 /2345/2346/2349/2363/ 2400/2402/2404/2405/2410 /2413/2418/2420/2439//2493/ 2494/2497/2508 /2569/2571/587/602/603/607/639 Technics 2043 Toshiba 2015/2021/2051 /2069/2090/2103/2137/2158/2159/2165/2179/2188/2194 /2208/2211/2213/2217 /2218/2222/2243/2244/2250/2271/2284/2288/2294 /2303 /2304/2313/2318/2319/2320/2321/2322/2328/2347/2350/2370/2375/2394/2409/24 21/2435/2437/2440/2465/466/467/485/487/489/490/496/497/503/508 /526/574/54/ 591/595/606/607/632/642 Dedicated Micros ©2009...

  • Page 113: Appendix C

    IP address of user, Local or Remote, Channel Controlled, Command sent Configuration Username, Local or remote, Menus changed, Items changed Playback Username, Remote, Channel viewed, From time Live Username, Remote, Channel viewed System Events Username, Event Info Dedicated Micros ©2009...

  • Page 114: Appendix D

    None Stop bits Flow Control None Power the unit, the Power LED on the unit will illuminate. Hyperterminal will display the communications information as the unit boots up. This will include the IP address, Subnet and Gateway. Dedicated Micros ©2009...

  • Page 115: Appendix E

    • Playback in quad, multiscreen, picture in picture and full screen. RECORDING Playback and record to hard disk simultaneously. Alarmed or manually selected images can be protected from being overwritten. Timed expiry option allows images to be held for a selected number of days. Dedicated Micros ©2009...
  • Page 116 Webpages are available for configuration and live viewing using a standard web browser KEYBOARD/RC INTERFACE CONTROL Offering full system control. OPTIONAL KEYBOARDS Supports Dedicated Micros keyboards: DMKBC1 DMKBC2 TELEMETRY Built-in RS485/Twisted pair protocols provide direct control of the numerous domes including but not limited to the following: •...
  • Page 117 Notes Dedicated Micros ©2009...
