Dedicated Micros SD Excel Installation Manual page 143

Text Filter
Line length
Number Visible Lines
Background Colour
Text Colour
Enable Keywords
Keywords pulse extension
Reset (Red)
Zone Act (Green)
Keywords (Yellow)
Serial (Blue)
Refresh (Purple)
Select the text filter option from the drop down list. The options are:
Plain Text (default), RAW, EPSON, Laserjet, DM POS Receipt, DM
POS Journal, TVC-1066
This identifies the length of the lines that will be stored with the image.
The default setting is 20 characters i.e. typically full screen.
To enable the text information to be viewed successfully, it is necessary
to establish how many lines of text will be visible
on screen.
A black background box appears by default around the text. It is
possible to change the colour of this box. Select from the drop down
list.
The colour of the displayed text can be changed. Select from the drop
down list.
This enables or disables the Keyword feature, allowing the unit to treat
certain pre-programmed words received via the text stream as event
triggers.Refer to 'Keywords' for guidance on creating Keyword triggers.
This time period allows multiple instances of a word received within
a period of time to be treated as a single event (i.e. if a configured
Keyword is detected again within the first Keyword's pulse extension
period, the second (and following) occurrences of the word will be
ignored).
Select to reset the unit.
Select to open the Alarm->Zone Actions menu
Select to open the Features & Text->Keywords menu
Select to open the System->Serial Ports menu
Refreshes the information on the current page
143
