Grid Editor
Reload Img (Red)
Set All (Green)
Clear All (Yellow)
Refresh (Purple)
Use the Grid Editor by placing cells in areas of the camera view where
movement will trigger an alarm. To enter cells navigate across the
image via the Directional buttons of the I.R Remote Control). If viewing
on a local monitor place a cell by pressing the OK button. If viewing via
the webpages, use the mouse to navigate across the image, use the left
mouse button to place a cell.
This option will update the still image displayed in the Grid Editor.
This option will insert a default square of 16 x 16 cells across the
displayed video image.
This option will clear all entered cells.
Refreshes the information on the current page.
