Change Scale - Dedicated Micros SD Excel Installation Manual

Change Scale

Utilise the buttons shown below to change the scale.
Note: The coloured softkey buttons can also be used to alter the scale, refer to "Softkey Guidance" for
further details).
Decrease Scale button (Red)
Increase Scale button (Blue)
Left Navigation Arrow (Green)
Right Navigation Arrow (Yellow)
172
Decreases the scale of the displayed timeline by one
step i.e. if the scale is currently one hour, selecting this
button will reduce it to 15 minutes, selecting it again
will reduce it to one minute etc.
Increases the scale of the timeline by one step i.e. if
the scale is currently one hour, selecting this button
will increase it to four hours, selecting it again will
increase it to one day etc.
Selecting the left navigation arrow will play recorded
images from the maximum prior time available via
the current timeline i.e. if a one hour time scale is
displayed, selecting the Left Navigation Arrow will play
video from one hour prior. This can also be selected
via the Green softkey button.
Selecting the right navigation arrow will play recorded
images from the maximum future time available via
the current timeline i.e. if a one hour time scale is
displayed, selecting the Right Navigation Arrow will
play video from one hour in advance. This can also be
selected via the Yellow softkey button.
