Hotspot X coord
Hotspot Y coord
Note: The hotspot can also be positioned by clicking directly on the map.
Hotspot Origin (deg)
Decrement (Red)
Increment (Green)
Map Data (Yellow)
Refresh (Purple)
60
Use to position the centre of the hotspot along the X axis e.g. entering
20 would place the hotspot centre 20 pixels from the left edge of the
map.
Use to position the centre of the hotspot along the Y axis e.g. entering
20 would place the hotspot centre 20 pixels from the bottom edge of the
map.
This option should be used when the hotspot relates to a Dedicated
Micros Oracle Dome camera. Clicking the hotspot will send the
Oracle Dome camera to a pre-determined view (absolute positioning).
However if the dead centre of the hotspot is selected, the camera will
be viewed from its current location.
The absolute positioning point will depend on the data entered here.
A setting of '0' would result in the camera facing its Original (base)
position. To change the preset position, enter a number between 1 and
360. A setting of 20 would set the preset position to 20 degrees to the
right of its 'origin' position, 180 would send it to face in the opposite
direction (of its base position) . Refer to the 'Viewer Menus-Program
menu' for information on establishing an Origin position for a PTZ
camera.
Select to reduce size of hotspot.
Select to increase size of hotspot.
Select to open the Display->Map Data page
Refreshes the information on the current page.
