1.8 CONFIGURATION

PLUS II permits the confi guration of default parameters.
The confi gurable parameters for PLUS II-S, PLUS II-S-0004 and PLUS II-T models, are:
Baud Rate : 38400, 19200
Data Length : 7, 8 bits/chr.
D
Parity : None , Even, Odd.
D
Handshaking : XON/XOFF
Autofeed: CR disabled
Columns: 24 col. , 40 col., 42 col.
D
Print Mode: Normal , Reverse.
D
Char Mode: Normal D , Double width (2 x Width), Double height (2 x Height), Expanded.
Print Density: -2, -1, 0
The confi gurable parameters PLUS II-C, PLUS II-C-0004 and PLUS II-P models, are:
Interface: Centronics, TTL.
Autofeed: CR disabled
Columns: 24 col.D, 40 col., 42 col.
Print Mode: Normal , Reverse.
D
Char Mode: Normal , Double width (2 x Width), Double height (2 x Height), Expanded.
D
Print Density: -2, -1, 0
The confi gurable parameters for PLUS II-USB model, are:
Emulation : PLUS II , ESC/POS.
D
Baud Rate : 38400, 19200
Data Length : 7, 8 bits/chr.
D
Parity : None , Even, Odd.
D
Handshaking : XON/XOFF
Autofeed: CR disabled
Print Mode: Normal , Reverse.
D
Char / inch : A=17 B=22 cpi
Notch Alignment : Disabled
• Notch Distance [mm x 10]
• Notch Distance [mm x 1]
• Notch Distance [mm x .1]
Print Density: -50%, -37%, -25%, -12%, 0
The parameters marked with the symbol
Note:
: If the "Notch Alignment" parameter is set to "Disabled" this parameter doesn't appear in the
Note (1)
"Printer Setup" report. The "Notch distance" parameter represents the distance in mm from the
upper margin of the ticket to the black mark on the ticket. For example, to set notch distance to
15mm, modify the following parameters in order to obtain the desired values as indicated: Notch
Distance [mm x 10]=1; Notch Distance [mm x 1]=5; Notch Distance [mm x .1]=0.
The settings made are stored in nonvolatile memory and are loaded automatically.
During power-up, if the FEED key is held down, the printer enters the autotest routine and prints out the setup
report. The printer will remain in standby in Hexadecimal dump mode (see par. 1.9) until another key is pressed
or characters are received through the printer communication port.
When the FEED key is pressed, the printer enters parameter confi guration. Each time the FEED key is pressed,
the parameter will change and the current value will be printed out. Once the desired value has been attained,
hold the FEED key down for at least a second to pass to the next parameter, and so on. Printing out of a new
printer set up report indicates that set up is complete.
, 9600, 4800, 2400,1200, 600.
D
D , or Hardware.
, CR enabled.
D
, +1, +2.
D
D , CR enabled.
, +1, +2.
D
, 9600, 4800, 2400,1200, 600.
D
, or Hardware.
D
D , CR enabled.
, A=13 B=17 cpi.
D
, Enabled.
D
: 0 D , 1, 2, 3, 4, 5, 6, 7, 8, 9.
(1)
: 0 , 1, 2, 3, 4, 5, 6, 7, 8, 9.
D
(1)
: 0 , 1, 2, 3, 4, 5, 6, 7, 8, 9.
D
(1)
D , +12%, +25%, +37%, +50%, linerless.
1. INSTALLATION AND USE
are the default values.
D
User Manual
PLUS II 1-13
