1.10.3 "EASYLOCK" fi xing system
This system allows to adapt the printer to every panel thickness and it is not necessary to use other fi xing tools.
A FIXING (see fi g.1.25)
• Use only the 2 hooks, provided in the package.
• Place the printer on the panel.
• Insert the 2 fi xing hooks in their seat.
• Push the 2 fi xing hooks against the panel to lock the printer.
B REMOVING (see fi g.1.26)
• Lift the fl ap by using a fl at screwdriver.
• Take away the hook.
A
NOTE:
The mounting operations are valid for all the PLUS II models.
B
(Fig.1.25)
1. INSTALLATION AND USE
PLUS II 1-17
User Manual
(Fig.1.26)
