A.1.3 Data and power supply cables kit for PLUS II-S and PLUS II-T
The printer can be supplied with a data and power supply cables starter kit.
PCSKPLUS
The kit includes (see fi g.A.9):
1. Power supply cable.
2. Data cable for serial interface.
1
2
To connect the cable proceed as follows (see fi g.A.10):
• Connect the power supply cable (1) to the power supply connector in the rear of the printer;
• Connect the data serial interface cable (2) to the interface connector in the rear of the printer.
A-6 PLUS II
User Manual
Starter kit cables for PCPLUS-S
500mm
1 2
(Fig.A.10)
(Fig.A.9)
