1.1 PAPER SPECIFICATIONS

Printer manage thermal roll (heat-sensitive side on outside of roll) or LINERLESS paper (see paragraph
1.1.1).
1.1.1 Specifi cations for LINERLESS paper
LINERLESS paper is a thermal paper with a self-adhesive layer without liner (on non heat-sensitive side). For the
better use with the printer the self-adhesive area must comply with the following dimensions (see fi g. 1.1):
HEAT SENSITIVE SIDE
(Fig.1.1)
LINERLESS PAPER SPECIFICATIONS
Self-adhesive
Self-adhesive mass
Total thickness
Total weight
Recommended temperature
Stick
Storage
Resistance after stick
10 42
57 ± 0.5
Water based acrylic
Permanent 16 gr/m
2
93 μm ±2 μm
96 gr/m 2 ±2gr
from +15°C to +40°C
from +10°C to +40°C
from -10°C to +50°C
1. INSTALLATION AND USE
5
±2gr
User Manual
SELF-ADHESIVE
