Custom Engineering PLUS II User Manual page 16

1. INSTALLATION AND USE
WARNING
Do not set "Printer Density" parameter on "Linerless" mode during the printer SETUP (see par.1.8)
with common thermal paper!
ATTENZIONE
In "Linerless" mode, if the printer is turned off a few hours, the fi rst row of the press could be com-
pressed, during the turning on. It is recommended to perform one or more paper FEED before
printing.
1.1.2 Specifi cations for label roll paper
Paper roll with alignment notch is permitted. To guarantee proper alignment, the "Notch Align." parameter must
be set to "Enable" during the SETUP procedure (see par.1.8).
The black notch must be placed on the heat-sensitive side of the ticket (printable area).
For the better use with the printer the label must comply with the following dimensions (see fi g. 1.2):
1-2 PLUS II
User Manual
0.5 mm
0.5 mm
25.75 mm 6.0 mm
HEAT SENSITIVE SIDE
5 mm
(Fig.1.2)
