APPENDIX A - ACCESSORIES AND SPARE PARTS
A.1.5 Data and power supply cables kit for PLUS II-C and PLUS II-P
The printer can be supplied with a data and power supply cables starter kit.
PCSKPLUS-C
The kit includes (see fi g.A.13):
1. Power supply cable.
2. Data cable for parallel interface.
1
2
To connect the cable proceed as follows (see fi g.A.14):
• Connect the power supply cable (1) to the power supply connector in the rear of the printer;
• Connect the data parallel interface cable (2) to the interface connector in the rear of the printer.
A-8 PLUS II
User Manual
Starter kit cables for serial PCPLUS-C and PCPLUS-P
500mm
1 2
(Fig.A.14)
(Fig.A.13)
