2.3.1 Connection Printer-PC

The following scheme, represent the connection cable confi guration between Molex connector 51021 series
15-pin (female) and a 25-pin connector (female). This cable can be use as wiring between the printer board
and a 25-pin connector (male).
AD0
1
AD1
2
AD2
3
AD3
4
AD4
5
AD5
6
AD6
7
AD7
8
BUSY
9
ERROR
10
PAPER END
11
ACK or FEED
JP5 (2)
12
STROBE
13
GND or LED
JP6 (2)
14
GND
15
Printer
NOTE
Signal not available with Centronics interface.
(1)
For JP5 and JP6 settings see paragraph 1.5.3.
(2)
(1)
PAPER END
1 2
User Manual
2. INTERFACES
STROBE
1
AD0
2
AD1
3
AD2
4
AD3
5
AD4
6
AD5
7
AD6
8
AD7
9
ACK
10
BUSY
11
12
13
14
ERROR
15
16
GND
17
GND
18
GND
19
GND
20
GND
21
GND
21
GND
23
GND
24
GND
25
PC
(Fig.2.6)
PLUS II 2-7
