Self-Test - Custom Engineering PLUS II User Manual

1. INSTALLATION AND USE

1.7 SELF-TEST

Printer operating status is indicated in the confi guration report in which, next to the name of the components
displayed (see fi g.1.12, fi g.1.13 and fi g.1.14), the following information is given:
• under PRINTER TYPE is given the printer model.
• under HEAD VOLTAGE is given the voltage of the printing head.
• under HEAD TEMPERATURE is given the temperature of the printing head.
(Fig.1.12)
PRINTER SETUP
HEAD TEMP. [°C]
HEAD VOLT [V]
Baud Rate ................. :
Data Length ............... :
Parity ......................... :
Handshaking ............. :
Autofeed .................... :
Columns .................... :
Print Mode ................. :
Char Mode................. :
Print Density.............. :
[PUSH] key to enter setup
[FAST PUSH] key to exit
RS232 Models
1-12 PLUS II
User Manual
= 32.5
= 5,00
38400 bps
8 bits/chr
None
Xon/Xoff
CR Enabled
24 col.
Normal
Normal
0
[PUSH] enter setup
[FAST PUSH] skip setup
PRINTER SETUP
PRINTER TYPE
HEAD VOLT. [V]
HEAD TEMP. [°C]
Emulation .................. :
Baud Rate ................. :
Data Length ............... :
Parity ......................... :
Handshaking ............. :
Autofeed .................... :
Print Mode ................. :
Chars / inch ............... :
Notch Alig. ................. :
Print Density.............. :
USB Models
PRINTER SETUP
HEAD TEMP. [°C]
HEAD VOLT [V]
Interface .................... :
Autofeed .................... :
Columns .................... :
Print Mode ................. :
Char Mode................. :
Print Density.............. :
[PUSH] key to enter setup
[FAST PUSH] key to exit
Centronics Models
= PLUSII-USB
= 06.58
= 24
PLUSII
9600 bps
8 bits/chr
None
Xon/Xoff
CR enabled
Normal
A=13 B=17 cpi
Disabled
0 %
(Fig.1.14)
(Fig.1.13)
= 32.5
= 5,00
Centronics
CR Enabled
24 col.
Normal
Normal
0
