SBC81700 VIA V4 SBC User's Manual
2.3

Jumper Settings

Proper jumper settings configure the SBC81700 to meet your
application purpose.
Jumper
Audio Line Out/Speaker Out: Line out
JP1
(Optional)
JP2 Power Supply Selection: ATX power supply Short 2-3
JP3 COM2 Mode Select: RS-232
JP4 COM2 Mode Select: RS-232
JP5 COM2 Mode Select: RS-232
JP6 Clear CMOS Setting: Normal

2.3.1 Audio Line-Out/Speaker Out Jumper (JP1)

This jumper makes the selection of Audio output.
Description
Audio Output
Selection
Note This is an optional jumper, not mounted as a default design.
8
Default Setting
Function
Line Out
(Default)
Speak Out
Jumper Setting
Short 1-3, 2-4
Short 1-2
Short 3-5, 4-6
Short 3-5, 4-6
Short 1-2
Jumper Setting
Jumpers and Connectors
