IDE Primary Master/Primary Slave
The categories identify the types of one channel that have been
installed in the computer. There are 45 predefined types and 2
users definable types are for Enhanced IDE BIOS. Type 1 to Type
45 is predefined. Type User is user-definable.
Press <PgUp>/<+> or <PgDn>/<−> to select a numbered hard disk
type or type the number and press <Enter>. Note that the
specifications of your drive must match with the drive table. The
hard disk will not work properly if you enter improper information
within this category. If your hard disk drive type does not match or
is not listed, you can use Type User to define your own drive type
manually.
If you select Type User, related information is asked to be entered
to the following items. Enter the information directly from the
keyboard and press <Enter>. This information should be provided
in the documentation from your hard disk vendor or the system
manufacturer.
If the controller of HDD interface is ESDI, select "Type 1".
If the controller of HDD interface is SCSI, select "None".
If the controller of HDD interface is CD-ROM, select "None".
CYLS. number of cylinders LANDZONE
HEADS number of heads
write precom
PRECOMP
If there is no hard disk drive installed, select NONE and press
<Enter>.
Dive A type
The item identifies the types of floppy disk installed in the computer.
None No floppy drive installed
360K, 3.5 in 3.5 inch PC-type standard drive; 360Kb Mini ITXcity
1.2M, 3.5 in 3.5 inch AT-type high-density drive; 1.2MB Mini
ITXcity
720K, 3.5 in 3.5 inch double-sided drive; 720Kb Mini ITXcity
1.44M, 3.5 in 3.5 inch double-sided drive; 1.44MB Mini ITXcity
2.88M, 3.5 in 3.5 inch double-sided drive; 2.88MB Mini ITXcity
Video
Select the display adapter type for your system.
Phoenix-Award BIOS Utility
SBC81700 VIA V4 SBC User's Manual
landing zone
SECTORS number of sectors
HDD access mode
MODE
