Super IO Device
Scroll to this item and press <Enter> to view the sub menu Super
IO Device.
Onboard FDC Controller
Select Enabled if your system has a floppy disk controller
(FDC) installed on the system board and you wish to use it.
If you install and-in FDC or the system has no floppy drive,
select Disabled in this field. The options available are
Enabled, Disabled.
Onboard Serial Port 1 / 2
Select an address and corresponding interrupt for the serial
port. Options: 3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3,
Disabled, Auto.
Onboard Parallel Port
This item allows you to determine access onboard parallel
port controller with which I/O address. The options available
are 378H/IRQ7, 278H/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
Select an operating mode for the onboard parallel (printer)
port. Select Normal unless your hardware and software
require one of the other modes offered in this field. The
options available are EPP1.9, ECP, SPP, ECPEPP1.7, and
EPP1.7.
