SBC81700 VIA V4 SBC User's Manual

4.11 PC Health Status

This section supports hardware monitoring that lets you monitor those
parameters for critical voltages, temperatures and fan speed of the
board.
Current CPU Temperature
These read-only fields reflect the functions of the hardware thermal
sensor that monitors the chip blocks and system temperatures to
ensure the system is stable.
Current SYSTEM Temperature
Show you the current system1 temperature.
Current CPU FAN Speed
These optional and read-only items show current speeds in RPM
(Revolution Per Minute) for the CPU fan and chassis fan as
monitored by the hardware monitoring IC.
Press <ESC> to return to the Main Menu page.
50
Phoenix-Award BIOS Utility
