Connectors

Connectors connect the CPU card with other parts of the system.
Loose or improper connection might cause problems. Make sure all
connectors are properly and firmly connected.
Here is a summary table shows you all connectors on the board.
Connectors
Audio Connector (optional)
Flat Panel Bezel Connector
ACPI Connector
Com1 Connector
Com2 Connector
USB1/2 Connector
USB3/4 Connector
LAN External LED Connectors
LAN Connectors
SATA Connector
VGA Connector
Keyboard External Connector
Mouse External Connector
USB5/6 Connectors
FAN Power connectors
DDRII DIMMs
Floppy Connector
IDE Connectors
LPT Port Connector
Jumpers and Connectors
SBC81700 VIA V4 SBC User's Manual
Label
AUDIO1
CN1
CN3
CN5
CN7
CN6
CN2
CN9, CN12
CN10, CN13
CN11
CN15
CN16
CN17
CN20, CN18
FAN1, FAN2
DIMM1, DIMM2
FDD1
IDE1, IDE2
LPT1
