2.4.9

VGA Connector (CN15)

The VGA connector CN15 is a standard 15-pin connector commonly
used for the CRT VGA display.
Pin Signal
1 Red
4 N.C
7 AGND
10 AGND
13 Horizontal Sync
2.4.10 Keyboard & Mouse External Connectors (CN16,
CN17)
The board provides the Keyboard and Mouse interface with two 5-pin
connectors CN16 and CN17.
Pin Signal
1 Clock
2 Data
3
4 GND
5 Power
Jumpers and Connectors
SBC81700 VIA V4 SBC User's Manual
Pin Signal
2 Green
5 AGND
8 AGND
11 N.C
14 Vertical Sync
N.C
Pin Signal
3 Blue
6 AGND
9 +5V
12 DDC DATA
15 DDC CLK
1
2
3
4
5
