H3C MSR 20-1X Installation Manual page 9

Item
Boot ROM
Memory
Flash
Physical dimensions (H × W ×
D) (excluding feet and
mounting brackets)
Weight
AC input
Maximum power consumption
Operating temperature
Relative humidity
(non-condensing)
NOTE:
The console port and AUX port of MSR 20-1X routers share one RJ-45 interface.
•
Two SIC slots can form one DSIC slot.
•
MSR 20-12 and MSR 20-15 can implement voice data processing without any VCPM card. If you need
•
voice support, insert a VPM card into the VPM slot on the main control board, and then install a
SIC-1VE1 or SIC-1VT1 on the router.
Only MSR 20-12 and 20-15 can support SIC-1VE1 and SIC-1VT1.
•
MSR 20-12, MSR 20-13, and MSR 20-15 all include two sub-models. One sub-model supports WLAN
•
and the other does not. You can purchase the appropriate sub-model as required.
The Boot ROM stores the Bootstrap for booting the router.
•
The memory stores the communication data between the system and the CPU during the system
•
operation.
The flash memory stores the BootWare, the software system and the configuration file of the router.
•
Do not unplug the USB device during USB data transmission; otherwise, data loss or even hardware
•
failures may occur.
The wireless module can not be purchased separately.
•
By default, the impedance of the fixed E1 interface on MSR 20-12 is 75-ohm. Using the internal DIP
•
switches, users can change the interface impedance from 75-ohm to 120-ohm. For detail information,
refer to Chapter 6 "Hardware Maintenance".
MSR 20-10 MSR 20-11
1 M in the 1 M in the
flash flash
memory memory
DDR 256 DDR 256
MB MB
32 MB 32 MB
44.2 × 300 44.2 × 300
× 240 mm × 240 mm
(1.74 × (1.74 ×
11.81 × 11.81 ×
9.45 in.) 9.45 in.)
3 kg (6.6 lb.) 3 kg (6.6 lb.)
Rated Rated
voltage voltage
range: 100 range: 100
VAC to 240 VAC to 240
VAC, 50 Hz VAC, 50 Hz
or 60 Hz
or 60 Hz
25 W 25 W
0°C to 40°C 0°C to 40°C
(32°F to (32°F to
104°F) 104°F)
5% to 90% 5% to 90%
2
MSR 20-12 MSR 20-13
1 M in the 1 M in the
flash flash
memory memory
DDR 256 DDR 256
MB MB
32 MB 32 MB
44.2 × 300 44.2 × 300
× 240 mm × 240 mm
(1.74 × (1.74 ×
11.81 × 11.81 ×
9.45 in.) 9.45 in.)
3 kg (6.6 lb.) 3 kg (6.6 lb.)
Rated Rated
voltage
voltage
range: 100 range: 100
VAC to 240 VAC to 240
VAC, 50 Hz VAC, 50 Hz
or 60 Hz or 60 Hz
25 W 25 W
0°C to 40°C 0°C to 40°C
(32°F to (32°F to
104°F) 104°F)
5% to 90% 5% to 90%
MSR 20-15
1 M in the
flash
memory
DDR 256
MB
32 MB
44.2 × 300
× 240 mm
(1.74 ×
11.81 ×
9.45 in.)
3 kg (6.6 lb.)
Rated
voltage
range: 100
VAC to 240
VAC, 50 Hz
or 60 Hz
25 W
0°C to 40°C
(32°F to
104°F)
5% to 90%
