Internal Structure
Figure 42 Internal structure of MSR 20-15
(4)
(1) SIC
(3) VPM
(5) Power
Replacing a VPM Card
Structure of VPM Card
Figure 43 Structure of VPM card
(2)
(1)
61
(3)
(6)
(5)
(2) Daughter card
(4) Removable slide rail
(6) WLAN card
