Hardware Maintenance

Preparing Tools

Phillips screwdrivers
•
Flathead screwdrivers
•
ESD-preventive wrist strap
•
Antistatic bag
•
NOTE:
The above tools are not shipped with the MSR 20-1X routers. You must prepare them by yourself.

Opening the Chassis Cover

Follow these steps to open the chassis cover:
Power off the router and remove the power cord.
Step1
Remove all cables from interface cards on the rear panel (keep the grounding cable connected).
Step2
Put the router on a table and have the rear panel face you. Loosen and remove the captive screws from
Step3
the rear panel with a Phillips screwdriver.
Put two flathead screwdrivers into the holes on both sides of the chassis and turn them until the tab on the
Step4
front panel is separated from the front panel.
Pull the cover horizontally a short distance, lift and remove it.
Step5
WARNING!
A dismantle-preventive seal is stuck on one of the screws of the router chassis. When you ask your sales
•
agent to maintain the router, you must ensure that the dismantlement-preventive seal on the screw is
intact.
The following procedure can only be carried out by a qualified service engineer.
•
Please read the safety instructions provided with this router before carrying out this work.
•
Ensure that no power is present for the sake of safety before maintaining the hardware.
•
Wear an ESD-preventive wrist strap and make sure that it makes good skin contact when maintaining
•
the hardware.
Only memory modules provided by our company are recommended for use. Otherwise, the router may
•
operate improperly.
60
