Configuring Ethernet Interface Parameters

Before upgrading an application program through an Ethernet interface, we need to configure the
Ethernet interface on the router as follows:
Enter 3 in the BootWare menu to enter the Ethernet interface submenu. Then, enter 5 to enter the change
Ethernet parameter submenu:
=========================<ETHERNET PARAMETER SET>=========================
|Note:
|
|
==========================================================================
Protocol (FTP or TFTP) :tftp ftp
Load File Name
Target File Name
Server IP Address
Local IP Address
Gateway IP Address
FTP User Name
FTP User Password
Table 24 Ethernet parameters settings description
Parameter
'.' = Clear field
'-' = Go to previous field
Ctrl+D = Quit
Protocol (FTP or TFTP)
Load File Name
Target File Name
Server IP Address
Local IP Address
Gateway IP Address
FTP User Name
FTP User Password
'.' = Clear field.
'-' = Go to previous field.
Ctrl+D = Quit.
:host
:
:target
:
:192.168.1.1
:192.168.1.253
:0.0.0.0
:user
:password
Description
To clear the current field, input a (.) and then press Enter.
To go to the previous field, input a hyphen (-) and then press Enter.
The shortcut key combination for exiting the parameter configuration
page is Ctrl+D.
Select a transmission protocol, FTP or TFTP.
Name of the source file, which must be consistent with the actual name
of the file to be downloaded.
Name for the target file to be saved. By default, it is the same as the
name of the source file on the server.
IP address of the FTP/TFTP server. To set a mask, separate the IP
address from the mask with a colon (:), for example,
192.168.80.10:24.
IP address of the local end, that is, the IP address of the FTP/TFTP
client.
Configure the gateway IP address if the server and the client are not
on the same network segment.
This option is not available for TFTP.
This option is not available for TFTP.
