After the power-on self-test (POST), the system prompts you to press Enter. When a command line
3.
prompt appears, you can proceed to configure the router.

Startup Process

After power-on or during the reboot process, the following information is displayed on the terminal:
System application is starting...
Booting Normal Extend BootWare...
**************************************************************************
*
*
*
**************************************************************************
Compiled Date
CPU Type
CPU L1 Cache
CPU Clock Speed
Memory Type
Memory Size
Memory Speed
BootWare Size
CPLD Version
PCB Version
BootWare Validating...
Press Ctrl+B to enter extended boot menu....
Press Ctrl + B to enter the extended Boot ROM menu. Otherwise, the system goes into the program
decompression process.
NOTE:
Press Ctrl+B within six seconds after "Press Ctrl+B to enter extended boot menu..." appears to enter the
extended Boot ROM menu. Otherwise, the system goes into the program decompression process. You
need to restart the router if you want to enter the extended Boot ROM menu after the decompression
process.
Starting to get the main application file--flash:/main.bin!.................
..........................................................................
........
The main application file is self-decompressing
Press Enter. The router enters user view and you can configure the router.

Configuration Fundamentals

In general, the router configuration steps are as follows:
MSR20-12 BootWare, Version 2.02
: Jul 29 2008
: MPC8323E
: 16KB
: 333MHz
: DDR SDRAM
: 256MB
: 132MHz
: 1024KB
: 1.0
: 3.0
