MSR 20-13 Router

Appearance
Front panel
1.
Figure 7 Front panel of the MSR 20-13 router
(1) Power LED (PWR)
(4) System LED (SYS)
(7) B2 LED
(10) Power switch
Rear panel
2.
Figure 8 Rear panel of the MSR 20-13 router
(1) Grounding terminal
(3) BRI S/T interface
(5) Layer 2 Ethernet interface 1
(7) Layer 2 Ethernet interface 3
(9) G.SHDSL.BIS LED
(11) SIC/DSIC slot
(2) ACT LED of BRI interface
(5) Ethernet LED (ETH)
(8) USB interface
(11) Power socket
(2) Console port/Auxiliary port (CON/AUX)
(4) Layer 3 Ethernet interface 0 (ETH0)
(6) Layer 2 Ethernet interface 2
(8) Layer 2 Ethernet interface 4
(10) G.SHDSL.BIS interface
8
(3) B1 LED
(6) Wireless LED (WLAN)
(9) RESET button
