Overview

Introduction

The MSR 20- 1 X routers are multifunctional access routers which are oriented to small and medium
business (SMB), enterprise branches, and home offices, and are designed to serve high-quality
orderwire and commercial networks. High-quality orderwire and commercial networks need to satisfy
the requirements for broadband access, wireless access, voice access, VPN, and QoS. In addition, the
network devices require high performance, stability, security, and manageability. MSR 20- 1 X routers are
cost effective. They provide different integrated communication interfaces for different communication
links and also provide an SIC/DSIC slot for expansion.
The MSR 20- 1 X routers include MSR 20- 1 0, MSR 20- 1 1, MSR 20- 1 2, MSR 20- 1 3, and MSR 20- 1 5. All of
them can be placed on a tabletop, or installed on a wall or in 19-inch standard cabinet. The following
sections will give you more details about these four models.

Physical Description of the MSR 20-1X Routers

Hardware Specifications

Table 1 Hardware specifications of the MSR 20-1X routers
Item
Fixed
Interfaces
External
Internal
Processor
MSR 20-10
Console/AUX 1
USB 1
Layer 3 Ethernet
1
interface
Layer 2 Ethernet
4
interface
ADSL 0
G.SHDSL.BIS 0
SA 0
ISDN BRI S/T 0
E1/T1 0
AM 0
SIC/DSIC slot 1
WLAN fixed
0
module
VPM slot 0
PowerPC
333 MHz
MSR 20-11 MSR 20-12
1 1
1 1
1 1
4 4
0 0
0 0
1 0
0 0
0 1
0 0
1 1
0 1 (Optional)
0 1
PowerPC PowerPC
333 MHz 333 MHz
1
MSR 20-13 MSR 20-15
1 1
1 1
1 1
4 4
0 1
1 0
0 0
1 1 (Optional)
0 0
0 1 (Optional)
1 1
1 (Optional) 1 (Optional)
0 1
PowerPC PowerPC
333 MHz 333 MHz
