EPSON Stylus Photo R1900/R2880/R2000
Observed Faults Details of the Fault
The printout is Ink smudges appear on the blank
stained with ink. area of the printout.
Troubleshooting
Table 3-15. Print Quality Troubles
Faulty Part/
Part Name
Front and Rear 1. Check the Front and Rear Paper EJ Roller Assys for ink stain.
Paper EJ Roller
Assys
Front Paper EJ Roller Assy
Driven Roller 1. Check the Driven Roller Shaft for ink stain.
Shaft
Ink System Unit 1. Check that wiping operation was performed properly.
Cleaner Blade
Overview
Check Point
Driven Roller Shaft
Rear Paper EJ Roller Assy
Revision E
Remedy
1. Clean the Front and Rear Paper EJ Roller Assys
with a soft cloth.
1. Clean the Driven Roller Shaft with a soft cloth.
1. Install the Cleaner blade correctly or replace it
with a new one.
