7. Hold the Carriage Unit, and while turning the Carriage Shaft, move the Carriage
Unit to the right end of the Carriage Shaft to lubricate the grease evenly.
Figure 6-18. Lubricating the Carriage Shaft (5)
8. Repeat Step 4 ~ 7.
