EPSON Stylus Photo R1900/R2880/R2000
Occurrence
Phenomenon Detail
Timing
At power-on After the Carriage has detected
the HP, an error is displayed on
the LED and STM3.
Occurrence
Phenomenon Detail
Timing
At power-on At power-on, the printer does not
operate at all.
Troubleshooting
Table 3-12. Troubleshooting of No Ink Cartridge/CSIC Error
Faulty Part/
Part Name
CSIC FFC 1. Check that the CSIC FFC is connected to the CSIC Board
connector and Main Board connector CN22.
CSIC FFC
CSIC Board
connector
2. Check the CSIC FFC for damage.
CSIC Board 1. Check the CSIC Board for damage.
Table 3-13. Troubleshooting of Maintenance Request
Faulty Part/
Part Name
Waste Ink Pads 1. Using the Adjustment Program, check if the values of the
Protection Counter A and B have exceeded the values shown
below.
• Protection Counter A : 21,500 (Stylus Photo R1900)
• Protection Counter B : 7,030
Overview
Check Point
CN22
CSIC Board
Check Point
: 22,500 (Stylus Photo R2880)
Revision E
Remedy
1. Connect the CSIC FFC to the CSIC Board
connector and Main Board connector CN22.
2. Replace the CSIC FFC with a new one.
1. Replace the CSIC Board with a new one.
Remedy
1. Replace the Waste Ink Pads and reset the
Protection Counter A and B value with the
Adjustment Program.
