EPSON Stylus Photo R1900/R2880/R2000
Occurrence
Phenomenon Detail
Timing
During printing After starting to print, ink is not
ejected and paper stops midway.
Ink is not ejected from most
nozzles.
Troubleshooting
Table 3-14. Troubleshooting of Fatal Error
Faulty Part/
Part Name
Head FFC 1. Check that the Head FFC is securely connected to the Print Head
connector and Main Board connectors CN11, CN12, CN13, and
CN14.
2. Check the Head FFC for damages.
Print Head 1. Check for occurrence of Head Hot.
Overview
Check Point
Head FFC
Print Head
connector
Revision E
Remedy
1. Connect the Head FFC to the Print Head
connector and Main Board connectors CN11,
CN12, CN13, and CN14.
2. Replace the Head FFC with a new one.
1. Replace the Print Head with a new one.
Confidential
59
