The VIA EITX-3000 is a high performance single board computer
(SBC) with low power requirements based on the Embedded ITX
(Em-ITX) form factor. Its low power requirements are made
possible by its usage of energy efficient VIA CPUs (either VIA
Nano™ or Eden™ ULV).
The EITX-3000 is designed for ultra-thin embedded applications
and can withstand temperatures ranging from -10° up to 70°C.
The powerful VIA Nano processor and VIA VX800 media system
processor are placed on the bottom side of the board, enabling
an efficient space-saving design that easily accommodates quiet
and passive cooling thermal solutions.
The EITX-3000 includes an onboard DC-to-DC converter that
supports both AT and ATX power modes. The power converter
can support a wide range of power input voltage from DC 7V to
DC 30V and can be configured through an onboard switch.
With generous support for multiple display options, the EITX-3000
is ideally suited for high-end multimedia applications including
POS, kiosks, ATM, HMI, factory automation, POI, and digital
signage. The dual I/O coastline design of the EITX-3000 provides
ample space for multiple ports such as two LVDS ports, one VGA
port, two Gigabit Ethernet ports, two USB 2.0 ports, two RS-232
COM ports, and two RS-232/422/485 configurable COM ports.
K F
EY EATURES
•
Onboard VIA Nano ULV processor (1MB L2 Cache)
•
Em-ITX (Embedded ITX) form factor with 17cm (W) x 12 cm (L)
•
Dual-side multiple I/O connector-coastlines
•
Onboard Em-IO expansion bus socket
•
Integrated VIA Chrome9 HC3, DC9 3D/2D graphics with
MPEG-2/4 and WMV9 video decoding acceleration
•
Onboard two of single channel LVDS display ports
•
Onboard two Gigabit Ethernets
•
Onboard two RS-232 and two RS-232/422-485, setup
through BIOS
•
Onboard six USB ports
•
Fan-less and Ultra Low power consumption
