VIA Technologies EITX-3000 User Manual page 14

Gigabit Ethernet Controller
• Onboard two VIA VT6130 Gigabit Ethernet controllers
Interface
• Support two RJ45 connectors
• Supports Wake On LAN (WOL)
• Support Preboot Execution Environment (PXE)
Audio Controller
• VIA VT1708B High Definition Audio Codec
Interface
• Support Line-in, Line-out, Mic-in connectors
USB 2.0 Onboard Six USB ports
• Two USB ports by a pair of mini-DIN connector
• Four USB ports by a pin headers with support of
Serial Ports Controller
• Onboard Fintek F81865 LPC I/O controller
Interface
• Support 4 COM ports
• Support RS-485 AutoFlow Control functions of COM1
Parallel Port Printer Port
• One PS/2 compatible bi-directional parallel port by a
DIO Digital I/O
• One 2x6-pin header- array to support 8-bit Digital IO
• Support 5V/12V power source
Storage Serial ATA
Interface • Onboard two SATA II ports, Maximum data transfer rate
• Only Support 2.5-inch of SATA Hard Disk (no support to
CompactFlash
• Onboard one socket support type I/II CompactFlash disk
Hardware Temperature Sensor
Monitoring • Built-in one Thermal Sensor by a 1x3-pin header onboard
System Indicator Power Status LED
• One green color LED
HDD Activity LED
• One red color LED
individual VCC power
• Two RS-232/422/485 by two DB-9 connectors as
COM 1 and COM 2, configurable via BIOS setup
• Two RS-232 by two DB-9 connectors of COM 3 and 4
and COM2
2x13-pin header onboard
up to 300MB/s
3.5" SATA HDD)
4
