Onboard Power Consumption
DC to DC Power • Typical 18.5W, Maximum 25.8W
Supply
Input Voltage
• Built-in onboard DC-to-DC converter
• Accept wide range of Power Input of DC 7V ~ 36V
• Typical Power Input
• Support AT and ATX mode
Power Input Connector
• One 2-pole Phoenix connector
AT/ATX
•
Fuse Rating
•
Physical Form Factor
• Em-ITX
Characteristics
Board Dimension (W x L)
•
Weight
•
Heatsink Construction
•
Dimension (W x H x D)
•
Environment Operating Temperature
Specifications •
•
Operating Humidity
•
Vibration loading during operation
•
• 7 V @ 2.64 A
DC
• 12 V @ 1.54 A
DC
• 16 V @ 1.15 A
DC
• 19 V @ 0.97 A
DC
• 24 V @ 0.77 A
DC
• 36 V @ 0.51 A
DC
Onboard AT/ATX switch by a 1x3-pin headers
7A / 125V
17 cm (W) x 12 cm (L)
0.98Kg (net weight of board plus heatsink only)
Aluminum Alloy mixed with Copper Heatsink
232.6 mm x 53 mm x 124.8 mm
Nano 1.3GHz version
(Part Number: EITX-3000-1N13A1 and EITX-3000-
2N13A1) is -10 to 65° C
Nano 1.0GHz version
(Part Number: EITX-3000-1N10A1 and EITX-3000-
2N10A1) is -10 to 70° C
10% ~ 90%, relative humidity, non-condensing
5Grms, IEC 68-2-64, random, 5~500Hz, 1 Oct./min, 1hr/axis
