- Page 1 Operating Guide EPIA EX-Series Mini-ITX Mainboard January 16, 2007 Version 1.01...
-
Page 2: Table Of Contents
EPIA EX-Series Operating Guide Table of Contents Table of Contents..................................... i VIA EPIA EX-Series Overview ..............................1 VIA EPIA EX-Series Layout ................................. 2 VIA EPIA EX-Series Specifications .............................. 3 VIA EPIA EX Processor SKUs..............................4 VIA CX700M2 All-in-One System Processor Overview......................5 VIA EPIA EX-Series I/O Back Panel Layout.......................... -
Page 3: Via Epia Ex-Series Overview
EPIA EX-Series Operating Guide VIA EPIA EX-Series Overview The VIA EPIA EX-Series Mini-ITX Mainboard is an ultra compact native x86 platform optimized for today's demanding embedded and productivity applications. The mainboard is based on the VIA CX700M2 advanced all-in-one system processor featuring an embedded hardware MPEG-2, MPEG-4 and WMV9 video decoding accelerator. -
Page 4: Via Epia Ex-Series Layout
EPIA EX-Series Operating Guide VIA EPIA EX-Series Layout January 16, 2007 - 2 - Version 1.01... -
Page 5: Via Epia Ex-Series Specifications
EPIA EX-Series Operating Guide VIA EPIA EX-Series Specifications Model Name - EPIA EX15000 - EPIA EX10000E Processor - VIA C7 1.5GHz NanoBGA2 - VIA C7 1.0GHz NanoBGA2 processor processor Chipset - VIA CX700M2 advanced all-in-one system processor System Memory - 1 DDR2 533 DIMM socket - Up to 1GB memory size - Integrated VIA UniChrome Pro II 3D/2D AGP graphics with... -
Page 6: Via Epia Ex Processor Skus
EPIA EX-Series Operating Guide VIA EPIA EX Processor SKUs The VIA EPIA EX-Series is available in two speed grades as follows: • 1.0 GHz VIA C7 NanoBGA2 Processor • 1.5 GHz VIA C7 NanoBGA2 Processor January 16, 2007 - 4 - Version 1.01... -
Page 7: Via Cx700M2 All-In-One System Processor Overview
EPIA EX-Series Operating Guide VIA CX700M2 All-in-One System Processor Overview The VIA CX700M2 All-in-One System Processor is designed to enable high quality digital video streaming and DVD playback in a new generation of fanless, small form factor PCs and IA devices. CX700M2 features the embedded VIA UniChrome™... -
Page 8: Via Epia Ex-Series I/O Back Panel Layout
EPIA EX-Series Operating Guide VIA EPIA EX-Series I/O Back Panel Layout The EPIA EX’s ultra compact 17cm x 17cm, integrated design supports connectivity options including one DVI port, one RJ45 port, two USB 2.0 ports, one S-Video port, one optical SPDIF port, one coaxial SPDIF port, one set of composite audio/video outputs and one set of component video outputs. -
Page 9: Via Epia Ex-Series Board Dimensions
EPIA EX-Series Operating Guide VIA EPIA EX-Series Board Dimensions 170.00 10.16 33.02 39.37 7.92 CX-700 165.10 170.00 6.17 6.35 January 16, 2007 - 7 - Version 1.01... -
Page 10: Via Epia Ex-Series Height Distribution
EPIA EX-Series Operating Guide VIA EPIA EX-Series Height Distribution Height:29.2mm 83.25 66.44 21.84 13.04 24.34 Height:33mm Height:34.5mm DIMM (34.6mm) Else height: under 21mm January 16, 2007 - 8 - Version 1.01... -
Page 11: Power Consumption
EPIA EX-Series Operating Guide Power Consumption Power consumption tests were carried out comparing the VIA EPIA EX running with VIA C7 1.0 GHz NanoBGA2 and VIA C7 1.5 GHz NanoBGA2 processors. The following tables are a comprehensive breakdown of the EPIA platform’s voltage, amp and wattage values while running common system applications. - Page 12 EPIA EX-Series Operating Guide E. Run C.C. Winstone 2004 Measured Voltage Measured Amp. Watts Main Board +3.3V 3.260 1.555 5.069 Main Board +5V 5.077 0.974 4.945 Main Board 5VSB 4.964 0.101 0.501 Main Board +12V 12.020 0.180 2.164 Main Board Power Consumption 12.679 F.
-
Page 13: Via Epia Ex 1.5 Ghz
EPIA EX-Series Operating Guide VIA EPIA EX 1.5 GHz A. Playing DVD – Power DVD 5.0 Measured Voltage Measured Amp. Watts Main Board +3.3V 3.280 1.589 5.212 Main Board +5V 5.064 1.419 7.186 Main Board 5VSB 4.955 0.100 0.496 Main Board +12V 12.030 0.204 2.454... - Page 14 EPIA EX-Series Operating Guide F. S3 Mode Measured Voltage Measured Amp. Watts Main Board +3.3V 0.000 0.000 0.000 Main Board +5V 0.000 0.000 0.000 Main Board 5VSB 4.980 0.125 0.623 Main Board +12V 0.000 0.000 0.000 Main Board Power Consumption 0.623 January 16, 2007 - 12 -...
-
Page 15: Power Specifications
EPIA EX-Series Operating Guide Power Specifications The EPIA EX utilizes an industry standard 20-pin ATX main connector to the power supply. Due to the EPIA EX platform’s ultra low power requirements a 90 – 120 Watt ATX power supply is ample for even the heaviest of multimedia system applications. -12V PWR_ON- PWR_GD... -
Page 16: Via Epia Ex-Series Microsoft And Linux Driver Support
EPIA EX-Series Operating Guide VIA EPIA EX-Series Microsoft and Linux Driver Support Microsoft Driver Support VIA EPIA EX series offers full support for the complete range of Microsoft operating systems. For standard operating systems, Windows 2000/XP latest drivers downloads can be found in the VEPD website at www.viaembedded.com. -
Page 17: Contact
EPIA EX-Series Operating Guide Contact For more information on the VIA EPIA EX-Series Mini ITX Mainboard contact your sales representative or visit our website at www.viaembedded.com Taiwan 440 Mission Court, Suite 220 1F, No. 531, Chung Cheng Road Fremont, CA 94539 Hsin Tien, Taipei 231 Tel: (510) 683 3300 Tel: (02) 2218 5452...
