Specifications - VIA Technologies EITX-3000 User Manual

S
PECIFICATIONS
Processor Core CPU
Logic System • VIA Nano Ultra Low Voltage Processor, compact
System Chipset
• VIA VX800 Unified Digital Media IGP chipset
• Supports 800 MHz Front Side Bus
BIOS
• Award BIOS
• 8Mbit SPI Flash BIOS
•Supports Plug & Play, APM 1.2
System Power Management
• Times Power On
• ACPI Supported
Battery
• Lithium 3V/48mAh
System Memory Technology
• One 200-pin SODIMM Socket support DDR2 533/667
Maximum Capacity
• Support memory size up to 2 GB
Graphic Controller
• Integrated VIA Chrome9 HC3 DX9 3D/2D graphics
Display Memory
• Optimized Unified Memory Architecture (UMA), supports
CRT Interface
• Onboard one VGA connector
• Pixel resolution support up 1920 x 1200(VGA)
LVDS Interface
• Support two of 24-bit single-channel LVDS interface
• Up to 1280 x 1024 panel resolution (Single Channel LVDS)
• Built-in Inverter control signals into the DB-26 connectors
• Onboard 5V/3.3V LCD power switch (default at 3.3V)
Dual Independent Display
• Support LVDS1 + LVDS2 at same resolutions, same pixel
• Support CRT + LVDS2 at same resolutions, same pixel
21 mm x 21 mm NanoBGA2 package:
• Nano 1.3 GHz (for Model of EITX-3000-1N13A1 and
EITX-3000-2N13A1)
• Nano 1.0 GHz (for Model of EITX-3000-1N10A1 and
EITX-3000-2N10A1)
SDRAM
engine with MPEG-2/4 WMV9 video decoding
acceleration built-in VIA VX800 Unified Digital Media IGP
chipset
up to 256 MB frame buffer using system memory
connectors as LVDS1/PANEL and LVDS2
depths, and same refresh rates
depths, and same refresh rates
3
