74 C
HAPTER

Starting the Program

1 Insert the bootable DOS diskette that contains the
3C985CFG.exe program into the floppy drive (for
example, the A drive).
2 Boot the computer from the bootable DOS diskette.
3 Enter this command to start the program:
a:\3c985cfg
The Configuration and Diagnostics Program detects all
3C985B-SX server NICs in the system. The main screen
appears with a NIC selected.
Slot numbers listed in the Configuration and Diagnostics
Program may not match those labeled on the mother board.

Navigating Within the Program

Table 7
the Configuration and Diagnostics Program.
Table 7 Using the Configuration and Diagnostics Program
Keystroke
Tab
Enter
Up and Down arrow keys
Esc
Shift+Tab
Alt+Highlighted letter
F1
F2
F3
F4
F5
F6
F7
F8
F9
F10
F11
F12
5: D
IAGNOSTICS AND
summarizes how to select items and move through
T
ROUBLESHOOTING
Action
Move cursor to next field
Select field
Move cursor up and down a list
Exit to previous screen
Move cursor to previous field
Execute indicated function
Get Help for selected item
Not applicable
Exit to DOS
Display Configure NIC screen
Display Run Tests screen
Display Test Setup screen
Start echo server
Display NIC Information screen
Display NIC Statistics screen
Select NIC
Not applicable
Not applicable
