Load Sharing; Namebind - 3Com EtherLink 3C985B-SX User Manual

load sharing

This command toggles outbound load sharing individually
for each Load Balancing/RSL group.
Syntax
Example
Default
Messages

namebind

This command creates a Load Balancing/RSL group
by specifying the slot-frame instance name of the
primary and secondary NICs (for example, p1_802.2
and p2_802.2).
Like the BIND command, the NAMEBIND command affects
all protocols and all frame types on the primary NIC.
(See
Syntax
Example
Default
Messages
el980lb load sharing pri_slot
where:
pri_slot is the PCI slot number of the primary NIC.
el980lb load sharing 10001
On
Displays the current state.
A separate message is displayed for each loaded
frame type.
bind for other properties.)
el980lb namebind primary_name secondary_name
where:
primary_name is the name of the primary slot.
secondary_name is the name of a secondary slot.
el980lb namebind p1_802.2 p2_8022
See bind.
See bind.
Load Balancing/RSL Commands 53
